Mqspac stretch wrapper with top plate Features

1)Exclusive design by MQSPAC;

2)Power pre-stretch  film carriage,ratio250%,film saving;

3)Cerificate:ISO9001/CE, meet the requirements of international standards;

5) Adopt international advanced manufacturing technology,  imported parts , components, electrical components;

5) PLC automatic program control, simple and convenient operation, low fault rate, low cost;

6) Auto imported height photoelectric detection, automatic height limit wrapped package;

7) 9 layer coated membrane way choice, to meet various requirements;

6)Auto height detection,turntable home position,forklift sockets for easy moving;

7)Strongly safety protection;

8) Dual limit switches on the top&bottom to provide better safety protections;

9) Film under the bottom of the rack configuration anti-collision device, protective film carriage, to ensure the safety of staff

10) film carriage ratio of 250%, for customers to save the packaging cost, improve the efficiency of the packaging, the best choice of packaging standardization;

12) Adopt domestic a line brand chain transmission, coping schedule not restricted, satisfies the requirement of highly diverse

13) Pressure plate use the soft foam, does not damage the product, use reliable;

Mqspac stretch wrap Specification

1.Turntable  Diameter:       1650mm             optional 1800mm,2000mm

2.Wrapping  Height:             2100mm

3.Loading  Weight:               1500kg(max)    (customized)

4.Packing  Speed:                 30-50 pallets/hour

5.Turntable Speed:              0-15rpm,speed variable,turntable soft &soft stop

6.Turntable Height:              82mm                 customized

8.Carriage Speed:                3m/min

9.Control:                              PLC program logic control

10.Working  Mode:             auto/manual

11. Pressure :            10 to 100 kg, adjustable

12. Pressure plate :       soft noodles + anticorrosive disc

13. press length:        unlimited

11.wrapping setings:                 wrap cycls/top wraps/bottom wraps/over wrap

11:Product size:                  L×W×H(2650×1650×2300)mm

12:Power:                            1 PH,220/110VAC,2Kw,20A

13.Film type: stretch film thickness 17-35microns, width 450-500mm, paper core76mm, max

      weight 18kgs
