700/850/1900/2100MHz 5-Band Cell Phone Booster for All U. S. Carriers

 G-Boost PR-X5-C1 Cellular signal booster is a small size, easy-to-use signal amplifier that Boosts the signals for cellular devices wherever you need. It covers Band/4/5/13/25 simultaneously. It improves the communication quality of your Devices where the area covers 200 square meters in public places or offices at the minimum cost, prolongs their battery life and, moreover, helps you to build A healthier environment by reducing undesirable radiation exposure on your Premise since your devices no longer need to search for signals all the time.

Features:


1)     Support voice and high-speed data service in 2G, 3G and 4G Mode; ;
2)     Automatically detect isolation between transmitting and receiving antennas, and Then adjust gain intelligently to avoid self-oscillates; meanwhile eliminate The impact within a network.
3)     MGC control function, it can adjust area coverage flexibility.
4)     Real-time monitoring the working status of product by LED indicating lamp.
5)     Smart size, easy to install.
6)     Meet the demand of the ROHS and FCC certification.

Technical details:



Frequency	700MHz Band17	700MHz Band13	850MHz Band5	2100MHz Band4	1900MHz Band25/2
Mode	GSM/CDMA/WCDMA/FDD-LTE
Output Power	Meet FCC standards
Gain	55dB	55dB	55dB	60dB	60dB
AGC Range	≥15dB
MGC Range	≥15dB
Noise Power	Meet FCC standards
Intermodulation	Meet FCC standards
Conducted emissions	Meet FCC standards
Radiated emissions	Meet FCC standards



2)     Mechanical Specifications

I/O Port	SMA-K
Impedance	50 ohm
Operating temperature	-10oC~+45oC
Power supply	AC 90~240V,50/60 Hz
Protection Level	IP40
Dimension	150mm*113mm*25mm(Main Equipment)
Weight	≤1.1kg(Contain Accessories)



Operation method of useage:





Package:
1)     Main equipment
2)     Power adapter
3)     Outside Antenna: Wall-mounted antenna
4)     Desktop antenna
5)     30 feet LMR200 cable
6)     User Manual

how to install the signal booster?

the company profile

Production line	Units
SMT line	2
Assemble production line	6 (including 1 completely automatic Assembly line)
Power Aging( ark)	30
test line	12
Package production line	4
Instrument	Units
Signal  Generator	25
Spectrum  Analyzer	26
Vector Network Analyzer	27
Power Supply	83
Nose Analyzer	2

Our service
