Usage: | Universal Testing Machine |
---|---|
Power: | Electronic |
Model Number: | XXG-2505 |
Brand Name: | DDYG |
Place of Origin: | China (Mainland) |
Max input: | 250 KV |
Max penetration: | 40 mm |
Xray tube material: | Ceram |
Quick Details
Specifications
Features
1. An overall self-diagnosis for software and hardware after startup can effectively detect the failure component.
2. Strong anti-interference properties make our X-ray Equipment can also work with electric generator in the wild field.
3. Quickly and exactly set exposure parameters by manual button.
4. High voltage can be started delayed to make enough time for personnel evacuate.
5. Slowly increase and decrease high voltage to protect X-ray generator
6. Duty cycle by 1:1
Specification
Items |
Parameters | |
Model |
XXG-2505 | |
Max. Penetration (A3 Steel) |
40mm | |
Focal Length |
600mm | |
Exposure Time |
5 minutes | |
Operation Temperature in Darkroom |
20±2°C | |
Developing Time |
5 minutes | |
Blackening |
≥1.5 | |
Sensitivity |
≤1.8% | |
Input |
Voltage |
AC198-240V/50Hz(60Hz) |
Capacity |
2.5kVA | |
X-ray Tube | ||
Focal Size |
2.0×2.0mm | |
Radiation Angle |
40 o | |
Output Voltage |
150-250kV(±2%) | |
Output Current |
5mA(±2%) | |
X-ray Generator | ||
Cooling |
Fan | |
Insulation |
SF6 | |
Pressure Gauge |
0.34MPa~0.45MPa | |
Dimension |
D320*H640mm | |
Weight |
30Kg | |
Control Unit | ||
Dimension |
350×290×150mm | |
Weight |
10Kg |
