| Brand Name: | Mrs sophie |
|---|---|
| name: | Mrs sophie |
| Material: | FRP |
| application: | FRP Cable Tray |
| Type: | frp |
Quick Details
Specifications
is available in polyester resin and vinylester resin, also referred to as GRP cable tray or fiberglass reinforced cable tray, non metallic cable tray. It is ideal for corrosive environments as well as applications that require non magnetic cable tray or non conductive cable trays. Our fiberglass cable tray are tested in accorandance with ASTM E84, class 1 flame rating and ASTM D635 self extinguishing requirements. A surface veil is applied during the pultrusion process to create a resin rich surface that is ultraviolet resistant.
FRP cable tray is very strong and can meet loading over 100 pounds perlinear foot on a foot span.
GRP Cable support system Benefits:
Economical Cable Support
Easy Installation
Fully Enclosed Cable Tray System
Smooth, Solid Bottom and Cover
Hides Cables from View
FRP cable tray is very strong and can meet loading over 100 pounds perlinear foot on a foot span.
Model |
Side Rail Heigh(mm) |
Loading Dept(mm) |
Flange |
Channel |
Tray Weight |
ST-01A |
75 |
46 |
25 |
4.8 |
2.93 |
ST-02A |
100 |
73 |
35 |
6.4 |
3.81 |
ST-03A |
100 |
70 |
28 |
6.4 |
4.55 |
ST-04A |
150 |
122 |
41 |
4.0 |
4.37 |
ST-05A |
150 |
122 |
41 |
4.8 |
4.37 |
ST-06A |
150 |
121 |
41 |
6.4 |
6.66 |
ST-07A |
150 |
119 |
41 |
8.0 |
7.34 |
ST-08A |
150 |
119 |
51 |
8.0 |
7.13 |
ST-09A |
200 |
170 |
44 |
8.0 |
9.60 |
ST-010A |
250 |
219 |
70 |
9.5 |
13.98 |
Remark: |
Other sizes are also can be customed by customer. | ||||
Economical Cable Support
Easy Installation
Fully Enclosed Cable Tray System
Smooth, Solid Bottom and Cover
Hides Cables from View
