After-sales Service Provided: | Engineers available to service machinery overseas |
---|---|
Warranty: | 12 months |
Certification: | ISO 9001 |
Brand Name: | Fote |
Condition: | New |
Weight: | 5600-17300kg |
Dimension(L*W*H): | 2500*1620*2600-4600*2350*3450 |
Power(W): | 37-180kw |
Model Number: | FTM06, FTM07, FTM09, FTM10 |
Place of Origin: | China (Mainland) |
Production Capacity: | 12-360TPH |
Quick Details
Specifications
Granite Sand Making Machine Manufacturer/Professional Sand Making Machine with ISO CE combines the latest design results with the advanced selective fragmenting principle, directly providing enough energy to the raw materials, then the material can be crushed by the energy. Granite Sand Making Machine Manufacturer/Professional Sand Making Machine with ISO CE makes the finished product rupture along the cleavage plane so that the powder has the natural texture face.The finished product has good grain shape and low consumption, which is more suitable for the requirement about the machine-made sand in construction site, high grade highway and railway site, hydropower project.
Working Principle of Granite Sand Making Machine Manufacturer/Professional Sand Making Machine with ISO CE
All materials into system sand machine into the hopper, the center of the feed opening into the high speed rotating sling wheel, within the sling wheel is accelerated rapidly, its acceleration can be up to several times the gravitational acceleration, and high-speed throw from the left wheel, first with the rebound after free fall impact the other part of the material, then hit with lining material (stone hit stone) or counter piece of stone (iron), bounced inclined upward shocks to the top of the vortex chamber, and change the direction of movement, deflecting downward movement, and the material impact emitted from the impeller passage to form a continuous material. In this way, a piece of the material in the vortex broken cavity by two chances to many times the impact, friction, and grinding crushing effect. Be broken material by bottom discharging mouth eduction.
Henan Fote Heavy Machinery Co., Ltd.Which is a professional manufacturer of many types of crushers, such as,Jaw crusher,impact crusher,hammer crusher,roller crusher,sand making machine,and other crushing equipments, Besides that, we can also supply grinding mills, rotary dryer, coal gasifier,etc.
