Type

SR-35N

SR-35NS

SR-35NH

SR-35NSH

SR-50N

SR-50NS

SR-50NH

SR-50NSH

SR-80N

SR-80NS

SR-80NH

SR-80NSH

SR-125N

SR-125NS

SR-125NH

SR-125NSH

SR-200N

SR-200NS

SR-200NH

SR-200NSH

Medium temp. Range

-120~ 250degree setting the max temp according to the supplier heating or cooling source)

-40135degree(the maximum temperature range can be operated by using glycol water formula.)

SR-  N

A set of cooling heat exchanger, heat exchanger, through proportional adjusting valve control cold heat into the heat exchanger, then through the uniform medium input to the reactor jacketed to do heat exchange and temp. Control, system has inside expansion tank.

SR-  NS

Besides SR- N function, add one set heater used to reduce high temp.

SR-  NH

Besides SR- N  function, add electrical heating function

SR-  NSH

Besides SR- N  function, add one set heater used to reduce high temp and electrical heating function

Tank capacity

100L

200L

280L

390L

500L

Heat exchanger area

3.5m2

5m2

8m2

12.5m2

20m2

Electric heating function H

25KW

35KW

50KW

65KW

80KW

with" H"  has heating function

Control mode

PID adaptive controller, special dynamic control calculation, Lneya controller

Communication

MODBUS RTU protocol RS485 interface,optional ethernet interface/R232 interface

Temperature control selection

Material control temp.

Temperature feedback

the temperature of three points: the inlet and outlet of heat-conducting medium, material in reactor(External temperature sensor), PT100 sensor

Material temperature feedback

Material temp. Feedback: PT100 or 420mA or communication given

Temp.Feedback: PT100

Material temperature accuracy

1

1

1

2

2

Circulating pump

200L/min 2.5BAR

250L/min 2.5BAR

400L/min 2.5BAR

500L/min 2.5BAR

750L/min 2.5BAR

Input, display

7-inch color touch screen display and touch key input, temp curve display

Security and protection

Self-diagnosis function; freezer overload protection; high pressure switch, overload relay,thermal protection device, liquid low level protection, high temperature protection and temperature fault protection.

Perform valve

Electric proportional control valve, control signal 4~20mA.

Piping material

SUS304

the interface size

DN40

DN40

DN-50

DN-65

DN-80

Installation dimensions

1000*1200*1750

1250*1250*2000

1500*1500*2050

2050*1450*2050

2050*1450*2050

POWER

AC380V 50HZ 1.6kw(max)

AC380V50HZ 2.1kw(max)

AC380V50HZ 2.5kw(max)

AC380V50HZ 5.7kw(max)

AC380V50HZ 7.7kw(max)

Suffix H power supply

AC380V 50HZ 26.6kw(max)

AC380V50HZ 37.1kw(max)

AC380V50HZ 52.5kw(max)

AC380V50HZ 70.7kw(max)

AC380V50HZ 87.7kw(max)

Shell material

SUS 304

SUS 304

SUS 304

SUS 304

SUS304
