LC MM OM3 SC-Type Adapter with ear

Fiber Optic Adapters are an important component in a fiber optic network; they are used in a fiber optic patch
Panel or any other outlet to mate two connectors. Fiber Optic adaptors are available for all standard connector
Types in both singlemode and multimode including Simplex and duplex versions. Our fiber optic adapters are
Made with high precision machines which ensure precise alignment for the connectors when they are plugged in. Fiber Optic Adaptors are color coded allowing easy identification of the adaptor type.

Connector Type	LC
Polish Type	UPC
Fiber Mode	Multi mode
Fiber Counts	Simplex
Insertion Loss	0.2dB

Specification

Parameter	Unit	LC,SC,FC,ST,MTRJ,MPO
		SM			MM
		PC	UPC	APC	PC
Insertion Loss(Typical)	dB	0.2dB	0.2dB	0.2dB	0.2dB
Return Loss	dB	45	50	60	30
Exchangeability	dB	0.2dB
Repeatability	dB	0.2dB
Durability	Time	>1000
Operating Temperature		-40~75
Storage Temperature		-40~85

Features

Accurate Mechanical Dimensions

Low Insertion Loss,high return loss

Excellent compatibility

Excellent repeatability

Excellent Temperature stability

No Polishing, no Epoxy

More Convenient to install

Application

Local Area Network

Optical fiber communication system

Optical access network(OAN)

Optical CATV

Optical fiber sensor

Fiber optics data transmission(FODT)

Active device termination

Equipment test
