| Brand Name: | KAMCAP |
|---|---|
| color: | not mentioned |
| Elongation at Break: | not mentioned |
| Min. Bending Radius: | not mentioned |
| Consistency of rod: | not mentioned |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Technical data
HP Series
Performance characteristics:, high power series
Typical application:RAM, Detonator, car recorder, smart meter, vacuum switch, digital camera, motor drive, clock circuit, UPS, toy, program-controlled switch, etc.
Series specification sheet:
Series name |
HP Series High power type |
Type name |
HP-2R7 |
Rated voltage VR |
2.7V |
Surge voltage |
2.85V |
Capacity range |
0.1F~3000F |
Operating temperature range |
-40 ~ +70 |
Product life |
Normal temperature cycle life:25, 1 million cycles between VR and 1/2VR, Capacity attenuation30%, ESR change4 times. |
High temperature endurance life:Maximum temperature retention VR,1000 hours.Capacity attenuation30%, ESR change4 times. |
Series specification sheet:
Series name |
HE Series High energy type |
Type name |
HE-2R7 |
Rated voltage VR |
2.7V |
Surge voltage |
2.85V |
Capacity range |
0.35F~25F |
Operating temperature range |
-25 ~ +70 |
Product life |
Normal temperature cycle life:25, 1 million cycles between VR and 1/2VR, Capacity attenuation30%, ESR change4 times. |
High temperature endurance life:Maximum temperature retention VR,1000 hours. Capacity attenuation30%, ESR change4 times. |
