| Brand Name: | GKNC |
|---|---|
| Input connector type: | TNC |
| Lightning protection: | NUll |
| Gain(dBi): | 28dB |
| Frequency range(MHz): | GPS L1 GLONASS L1 BD2-B1 |
| Model Number: | GK-AIR3F |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Features:
1. Frequency Range: GPS L1 GLONASS L1 BD2-B1
2.Feed points: 1
3. Impedance: 50
4. Polarization: Dextroclination circular polarization
5. Axial Ratio: 3dB
6. VSWR: 1.5
Technical details:
1. LNA Gain: 262dB
2.Noise Figure: 1.5dB
3. Operation Voltage: 5v
4. Operation Current: 40mA5v
Operation method of useage:
1. Operating Temp: 5085
2. Storage Temp: 5585
3. Humidity: 95%
GK-XF's lightweight yet rugged design combined with low power consumption make it an ideal antenna for almost any environment.
