| After-sales Service Provided: | Overseas third-party support available |
|---|---|
| Brand Name: | United Asia |
| Style: | Horizontal |
| Type: | Rip Saw |
| Condition: | New |
| Warranty: | 2 yesrs |
| Certification: | ISO9001 |
| Weight: | 855 |
| Dimension(L*W*H): | 1600 x 1330 x 1490mm |
| Power(W): | 8.25KW |
| Voltage: | 380v |
| Usage: | new |
| Model Number: | MJ162A |
| Place of Origin: | China (Mainland) |
| Use: | Woodworking |
Quick Details
Specifications
the following example is for you reference.
1.Brief Introduction:
1. the principle of saw cutting under the wood makes the cutting process more steady and smoothly also safer for operating.
2.Techincal parameters:
Saw blade diameter 255-355mm Max.Processing thickness 80mm Short processing length 250mm Spindle width Left 300/right 460mm Spindle speed 2900r.p.M Spindle diameter 50.8mm Feeding speed 3-26m/min Main motor power 7.5kw Feed motor power 0.75kw Total power 8.25KW Blade thickness 3.2-5.0mm Working desk size 850 x 1400mm Dimensions 1600 x 1330 x 1490mm Machine weight 855kg
3.Performance features:
12. the front feeding entrance safety plate is made of heat treating steel, it is steady and will prevent the rebound of the wood exactly.
