| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Condition: | New |
| Brand Name: | chushidun |
| Weight: | 6500 |
| color: | green |
| Model Number: | T45/T63/T80 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Designation of uncoiler machine
1, Max roll diameter 1000 MM
2, Max width of the material 550 MM
3, Feeding speed 10-50 M/MIN
4, Feeding length 30-999 MM
5, Feeding accuracy ±0.6 MM
6, Net weight 1000 KG
7, Dimension 154012501100MM (LWH)
* We have 2 type Umcoiler machine: Common feeding machine and embossing feeding machine
Designation pressure
1, Stroke time 20-110TIME/MIN
2, Stroke height 200MM
3, Max die installation height 440MM
4, Height adjustment for die 80MM
5, Distance from the center of slice to the body 340MM
6, Dimension of Slide block bottom, Size of handle hole 320145MM, φ18
7, Work plate dimension 6601000MM
8, Body work plate hole dimension 300300MM
9, Work plate thickness 50MM
10, Slice underside dimension 220400MM
11, Die handle hole dimension φ5060MM
12, Dimension 165013502800MM (LWH)
13, Net weight 5000KG
*the precise press machine adopts steel plate welding body, dry friction clutch, overload protector, features high preciseness, reliable operating.
by select
Automatic container stacker
1, Collector Belt Width 550mm
2, Collector Belt Height 920±25mm(Adjustable height system on request)
3, Min. Container dimensions 100*100mm(smaller on request)
4, Max. Container dimensions
500*300mm(1 ways)
215*300mm(2ways)
5, Max. Height of the stacker 420mm(depend on the container shape and size)
6, Lifting system by step motor and linear guide
7, Photocell with Electronic counting device
8, Container counter automatically stops press at top of
9, stroke in emergency situations
10, Control Panel Touch screen
11, Stacking SystemPhotoelectricity Control the high of stacker, electric brake system
12, Installed power 3KW
13, Air consumption(2ways) 0.2m3/Min
14, Net. Weight 1000kg
15, Stacker Dimensions3300*1010*1290mm(±25mm)(LWH)
* we can develop according to a special container stacking machine
800 Automatic stacker(3way):
Collector Belt Width:800mm
Collector Belt Height:920±25mm (Adjustable height system on request)
Min. Container dimensions:100*100mm(smaller on request)
Max. Container dimensions:750*300mm(1 ways) the ways can be reduce by yourself,
350*300mm(2ways) also depend on the container's shape!
200*300mm (3 ways) Max. Height of the stacker:500mm(depend on the container shape and size)
Lifting system,by step motor and linear guide,Photocell with Electronic counting device'Container counter automatically stops press at top of stroke
in emergency situations,Control Panel'Touch screen,Stacking System,Photoelectricity Control the high of stacker, electric brake
System,Installed power:3KW
Air consumption(2ways):0.2m3/Min
Net. Weight:800kg
Stacker Dimensions(L*W*H)
3300*1010*1500mm(±25mm)
Mould
Mould/die is made of high quality die steel, with the function of edge trimming and curling.
*we can make two or three cavity about one mould if you need.
Scrap collector
1, Speed 1450rpm
2, High-lift 1000mm.
3, install poewer 4KW.)
