| Brand Name: | Optech |
|---|---|
| Wavelength: | 850nm |
| Data Rate: | 400Gb/s |
| warranty: | 1 year |
| Connector: | MPO-16 |
| Model Number: | OPDY-MX1-85-CB |
| Place of Origin: | Taiwan |
Quick Details
Specifications
Features
* QSFP-DD MSA compliant
* 8 parallel lanes on 850nm center wavelength
* Compliant to IEEE 802.3bs Specification
* up to 100m transmission on multi-mode fiber
(MMF) OM3 with FEC
* Operating case temperature: 0 to 70°C
* 8x53.125Gb/s electrical interface (400GAUI-8)
* Data Rate 53.125Gbps (PAM4) per channel.
* Maximum power consumption 12W
* MPO-16 connector
* RoHS compliant
Applications
* Data Center Interconnect
* 400G Ethernet
* Infiniband interconnects
* Enterprise networking
* QSFP-DD MSA compliant
* 8 parallel lanes on 850nm center wavelength
* Compliant to IEEE 802.3bs Specification
* up to 100m transmission on multi-mode fiber
(MMF) OM3 with FEC
* Operating case temperature: 0 to 70°C
* 8x53.125Gb/s electrical interface (400GAUI-8)
* Data Rate 53.125Gbps (PAM4) per channel.
* Maximum power consumption 12W
* MPO-16 connector
* RoHS compliant
Applications
* Data Center Interconnect
* 400G Ethernet
* Infiniband interconnects
* Enterprise networking
