| Brand Name: | Optech |
|---|---|
| Wavelength: | 1310nm |
| Data Rate: | 400Gb/s |
| warranty: | 1 year |
| Connector: | MPO-12 |
| Model Number: | OPDY-S02-13-CBS |
| Place of Origin: | Taiwan |
Quick Details
Specifications
Features
* QSFP-DD MSA compliant
* Parallel 4 Optical Lanes
* 100G Lambda MSA 400G-FR Specification compliant
* up to 2km transmission on single mode fiber (SMF) with FEC
* Operating case temperature: 0 to 70°C
* 8x53.125Gb/s electrical interface (400GAUI-8)
* Data Rate 106.25Gbps (PAM4) per channel.
* Maximum power consumption 12W
* MPO-12 connector
* RoHS compliant
Applications
* 400G Ethernet
* Infiniband interconnects
* Datacenter Enterprise networking
*
* QSFP-DD MSA compliant
* Parallel 4 Optical Lanes
* 100G Lambda MSA 400G-FR Specification compliant
* up to 2km transmission on single mode fiber (SMF) with FEC
* Operating case temperature: 0 to 70°C
* 8x53.125Gb/s electrical interface (400GAUI-8)
* Data Rate 106.25Gbps (PAM4) per channel.
* Maximum power consumption 12W
* MPO-12 connector
* RoHS compliant
Applications
* 400G Ethernet
* Infiniband interconnects
* Datacenter Enterprise networking
*
