Due to its application prospects in solar-blind ultraviolet detection, MgZnO alloy semiconductor films with suitable band gaps have attracted more and more attention. A series of MgxZn1-xO thin films with different compositions were prepared on M plane sapphire wafers by using low-pressure metalorganic chemical vapor deposition (LP-MOCVD).



CRYSCORE provides M plane (10-10) sapphire wafers with excellent surface quality. the roughness on the epi-polished side is lower than 0.5 nm.

Specifications of M-Plane (10-10) Sapphire Wafers

Item	2-inch M-plane(10-10) 430μm Sapphire Wafers
Crystal Materials	99,999%, High Purity, Monocrystalline Al2O3
Grade	Prime, Epi-Ready
Surface Orientation	M-plane(11-10)
Diameter	50.8 mm +/- 0.1 mm
Thickness	430 μm +/- 25 μm
Primary Flat Orientation	C-plane(0001) +/- 0.2°
Primary Flat Length	16.0 mm +/- 1.0 mm
Single Side Polished (SSP)	Front Surface	Epi-polished, Ra < 0.5 nm (by AFM)
	Back Surface	Fine ground, Ra = 0.8 μm to 1.2 μm
Double Side Polished (DSP)	Front Surface	Epi-polished, Ra < 0.5 nm (by AFM)
	Back Surface	Epi-polished, Ra < 0.5 nm (by AFM)
TTV	< 10 μm
BOW	< 10 μm
WARP	< 10 μm
Cleaning / Packaging	Class 100 cleanroom cleaning and vacuum packaging, 25 pieces in one cassette packaging or single piece packaging.



Note: Custom sapphire wafers with any orientation and any thickness can be provided.



Our sapphire wafer cost you less and help you to achieve more, contact us to get more information.
