the  bracket is a combination consisting of a cable bracket, a post and a fixed pin. the material of the column and the pin is also made by the high temperature pultrusion of the FRP composite. the column can be arbitrarily cut length according to the needs, the height of the layer is adjusted, and the assembly is free. the cable bracket has various specifications to meet different lengths and load requirements.



Light weight, high strength, aging resistance, UV protection, more importantly, 1 mm can withstand voltages above 10,000 volts, it is a good insulation material.



Features: high insulation, chemical resistance, high fire resistance, good water resistance, accurate size, stable working performance, light weight, high strength, acid and alkali resistance, waterproof, moisture-proof.



SMC Cable Braket Specification



Project	SMC Cable Braket	Galvanized angle bracket
Density (g/cm3)	1.80	7.85
Specific strength	167	90
Corrosion resistance (80°/100h)	0.012	0.023
Insulation strength (kv/mm)	14.0	Conductive
Flame retardancy	Meets the FH-1	--
Water resistance (%)	0.11	--
Corrosion resistance	Corrosion, acid, alkali, salt resistant	Corrosive, easy to rust
Insulation	Insulation	Conduction
Mechanical strength	Top force 2.5kN deflection 1.0cm	Top force 2.5kN deflection 1.2cm
Lateral force 0.5kN	Top horizontal offset 7cm	Top horizontal offset 7cm
Weight	light	Weight
Eddy current effect (loss)	no	Large loss
Manufacturing process is difficult	easy	Many processes and long cycle
Cable outer sheath scraping test	No visible damage	There is a little visible damage
Raw material	Cheap, resource-rich	More expensive, partially imported
Maintenance	Free maintenance	5-7 years need to be repaired once
Installation process is difficult or easy	Short time and easy to install	Long time, difficult to install
Use life	30 years	10 years

SMC and  require heating rather than cooling systems. The temperature of the mold is usually between 130 and 160. It is very important to keep the temperature of the mold and the exhaust gas when designing the mold. The mold is easier to fill, the product is not easy to be deformed, and the surface is better. Commonly used heating systems are steam, oil and electric heating rods.
