Battery Pack Normal performance

1.Battery Type: LiFePO4 battery

2.Standard Capacity (1C): 60Ah

3 Rated voltage: 51.2V  (Work Voltage)

 4 Rate Power: 3072Wh  (3.072 kWh)

5 Internal Impedance:  <50 MΩ  (Internal Resistance measured at AC 1kHz after 50% charge)

6 Max.Charge voltage:  58.4 V(Voltage of Charger Selection)

7 Cut-off voltage:  40V(BMS discharge voltage cut- off)

8 Standard charge current: 20~50A( Max charge Current 50A)

9 Continuous discharge current: 0~60A

10 Max Continuous discharge current:150A  (10 Seconds) (Adjustable)

11 Battery dimension:(420±5mm)*(300±5mm)*(280±5mm)  Adjustable

12Total Weight (Approx.):Approximately 30kg ( Including counterweight )

13 Charge method (CC/CV):

Standard :0℃45℃,Charge

Discharge :-20℃60℃

Storage: -20℃45℃

14 Capacity:@ shipment  50%-60%
