| Nominal Capacity: | 2300 |
|---|---|
| Weight: | See Below Table |
| Size: | See Below Table |
| Usage: | UPS |
| Brand Name: | Csbattery |
Quick Details
Specifications
CSBattery High-Temp Deep cycle GEL Battery 12V/6V/8V
Deep Cycle GEL Batteries 12V100Ah, 150Ah, 200Ah most popular models Advanced Features:
Environmentally friendly Completely Maintenance-Free Non-Spillable construction design.
Wide Operating Temperature Range(-20°C~+60°C) Longer Life(20years designed life) Explosion Proof
Valve Regulated & High Discharge Rate Capability Low Self Discharge Independent of Position
Ease of Shipment No need of balanced charge or boost No Memory
Chinese Best Quality Solar GEL Battery Sunny Battery Applications:
Communication equipment Telecommunication control equipment Emergency lighting systems Electric power systems Power station
Nuclear power station Solar powered and wind powered systems Load leveling and storage equipment Marine equipment Power generation plants
Alarm systems Uninterruptible power supplies and stand-by power for computers Medical equipment Fire and security systems Control equipment
Stand-by electric power.
CSBattery High-Temp Long Life GEL Deep Cycle Battery HTB 12-200
HTB12V Patented High-Temp Deep Cycle Solar gel battery, own 15-20years long life, your best partner for solar market and hot area.
CSBattery HTB series of 12V Solar GEL deep cycle batteries are recognized as the most reliable and high quality battery system in the industry. They are designed with advanced patented GEL technology, Long service life designed with 15-20 years, 50% DOD 1500-1600 Cycles, the batteries comply to the most popular international standards, such as IEC60896-21/22, BS6290-4, Eurobat Guide. Deep Cycle GEL Batteries 12V100Ah, 150Ah, 200Ah most popular models Advanced Features:
Environmentally friendly Completely Maintenance-Free Non-Spillable construction design.
Wide Operating Temperature Range(-20°C~+60°C) Longer Life(20years designed life) Explosion Proof
Valve Regulated & High Discharge Rate Capability Low Self Discharge Independent of Position
Ease of Shipment No need of balanced charge or boost No Memory
Chinese Best Quality Solar GEL Battery Sunny Battery Applications:
Communication equipment Telecommunication control equipment Emergency lighting systems Electric power systems Power station
Nuclear power station Solar powered and wind powered systems Load leveling and storage equipment Marine equipment Power generation plants
Alarm systems Uninterruptible power supplies and stand-by power for computers Medical equipment Fire and security systems Control equipment
Stand-by electric power.
-------------------------------------------------------------------------------------------------
CSBattery High-Temp Long Life GEL Deep Cycle Battery HTB12-200 specification
CSBattery High-Temp Long Life GEL Deep Cycle Battery HTB12-200 specification
| HTB12-200 | |||
| Nominal Voltage | 12V (6 cells per unit) | ||
| Design Floating Life @ 25C | 20 Years | ||
| Nominal Capacity @ 25C | 20 hour rate@ 21.0A, 5.4V | 200Ah | |
| Capacity @ 25C | 10 hour rate (37.8A, 5.4V) | 180Ah | |
| 5 hour rate (66.8A, 5.25V) | 159Ah | ||
| 1 hour rate (233.3A, 4.8V) | 115.5Ah | ||
| Internal Resistance | Full Charged Battery@ 25C | ≤3mΩ | |
| Ambient Temperature | Discharge | -25C~60C | |
| Charge | -25C~60C | ||
| Storage | -25C~60C | ||
| Max.Discharge Current | @ 25C 1200A(5s) | ||
| Capacity affected by Temperature (10 hour ) | 40C | 108% | |
| 25C | 100% | ||
| 0C | 90% | ||
| -15C | 70% | ||
| Self-Discharge@25Cper Month | 3% | ||
| Charge (Constant Voltage) @ 25C | Standby Use | Initial Charging Current Less than 45.0A Voltage 13.6 - 13.8V | |
| Cycle Use | Initial Charging Current Less than 45.0A Voltage 13.6 - 13.8V | ||
| Dimension (mm*mm*mm) | Length 532±1 * Width 206±1 * Height 215±1 (Total Height 219±1) | ||
| Weight (kg) | 58.6±3% | ||
