LTE

LTE CAT4

  LTE FDD Downlink: 150Mbps  Uplink: 50Mbps

  LTE TDD Downlink: 130Mbps  Uplink: 30Mbps

LTE Bands Combo

Q1: LTE Band 1/3/7/8/20/38/40/41; 3G Band 1/2/5/8
Q2: LTE Band 1/2/4/7/12/38/40/41; 3G Band 1/2/5/8
Q3: LTE Band 1/2/4/7/28/40; 3G Band 1/2/4/8
Q4: LTE Band 3/7/20/42/43

*the bands could be designed according to the operator bands





Data Network

Ethernet Port:  4x10/100Mbps Ethernet Port LAN

                 or 1x10/100Mbps Ethernet Port WAN+3x10/100Mbps Ethernet Port LAN

Static IP address, PPPoE, DHCP
PnP: Auto detection-line,upgrade
QoS: Destination/Source MAC/IP, Application, DSCP
Advanced Routing: Static Route, Policy Route, DNS Proxy,
                              Port Forwarding/Triggering
Internal Address Management: DHCP Server, IP and MAC Address Bind,

                                              DHCP Relay
Networking Protocols: TCP/IP(IPv4/v6), UDP, RTP, SNTP,
                                  NAT, DHCP, DNS, DDNS

. LTE Features: Switch Frequency Band, Multi -APN,

                     Lock/Switch PLMN, Lock SIM Card, SMS
VPN: IPSec, PPTP, L2TP, EOIP
Management Protocol: CLI, SNMPV1/2, TR069, WebStatic

Firewall & Security: IDS&IPS, Block Ping/ICMP/IDENT,

                              IP and MAC Address Bind, SPI Firewall, Port scan restriction



WiFi Features
IEEE 802.11b/g/n (2.4Ghz)
Security: WEP, WPA, WPA2, WPA-PSK, WPA2-PSK
WiFi Features:WMM, WLAN-LAN Isolation, Multi SSID(X4), AP Isolation
Antenna Type: 2R2T WiFi b/g/n

WiFi Speed: WiFi N  300Mbps



Voice Features (Optional)

2*FXS Port G.711Alaw, G711mulaw, G.723, G.729

SIP T.30/T.38 fax

Billing mode: Reverse Polarity

Voice Functions: Caller detection and Caller ID;  Call waiting,

                          Call transfer, Call forward, abbreviation dial,

                          3-Way Conference, Do-Not-Disturb



Environment

Dimension: 190 x 125 x 30mm
Net Weight 600 g
Power Supply: 12V/1A
Operation Range: 0° to 40°C, 32°to 113°F
Humidity:10-90% non-condensing
