Hardware Specifications:
5* 10/100/1000Mbps Ethernet ports
1* 100/1000Mbps SFP optical port
2* SIM card slot
2* 4G antenna
2* WiFi antenna
1* FUNC button

1* GPS antenna(optional)

1*USB Port
2* 3 standard core power interface
4G/3G/2G access (the frequency bands could be customized)
WiFi module: 802.11 b/g/n, 300Mbps dual channel
Dimension: 179mm*135mm*34mm
Structure design: the high-duty metal case
Power consumption: ≤15W
Input: DC12V/1.5A
Operating temperature: -40+85°C
Operating humidity: 1095%RH
Store temperature: -40+85°C
Installation: desktop, wall-mounted, slideway



Key features:

Various network protocols: TCP/IP, UDP, HTTP, TELNET, ICMP, DHCP, PPPoE, DNS etc.

Port setting: Port Mirroring, Flow Statistics, LAN and WAN Port Setting
Multi-WAN Function

  LTE+SFP Fiber+Ethernet Load Balancing

  WAN Load Balancing: Bandwidth Occupancy, WAN IP Tracing

  WAN Bandwidth Percentage Display

  LAN IP Statistics

  Detecting Online: ICMP Detecting, ICMP Detecting

 Static routing and dynamic routing of RIP/OSPF/BGP
PWE3, VPLS, L3 VPN
QoS: packets priority, traffic policing, traffic shaping,rate-limiting
Centralized network management of CLI, WEB and SNMP
NAT function
ACL function
Firewall, packet filtering etc
VPN functions: GRE, L2TP VPN, IPSec VPN, EOIP VPN, MPLS VPN etc.

                       (VPN optional, GRE over IPSec, IPsec over L2TP.)
802.1Q VLAN and QinQ
Link detective functions such as BFD, DLDP(switch to backup link according to detective result quickly)
Log function
