Hardware

2*Gigabit Ethernet LAN

1*2.5Gbps Ethernet LAN

1*RJ11 for  Voice

Dual band WiFi6: IEEE802.11 a/b/g/n/AC/ax

1*SIM Card Slot

1*Power Supply

Built-in  3/4/5G Antennas

Built-in WiFi Antennas

Buttons:

  Power, WPS, Reset

LED Indicators:

  Power, 5G, 4G,, WiFi, WPS

5G/4G/3G

5G NR:

  Bands: N2/N5/N12/N41/N66/N71/N77/N78/N79

  MIMO 4x4, 256QAM

  Downlink up to 4Gbps

  Uplink up to 300Mbps

LTE:

  FDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B17/B20/B25/B26/B66/B71

  TDD: B38/B39/B40/B41/B42/B43/B46/B48

  LTE Cat 22

  MIMO 4*4, 256QAM
  Downlink up to 2.4Gbps
  Uplink up to 200Mbps

WCDMA:

  B1/B2/B4/B5/B8

*the bands could be designed according to the operator bands

WiFi 6

IEEE802.11 a/b/g/b/AC/ax

2.4Ghz + 5.8GHz

MIMO  4X4

Security: Open, WPA-PSK, WPA2-PSK,  WPA3-PSK

5G NR to WiFi Throughput: up to 3Gbps

Features
Voice

  VoIP, VoLTE, CSFB
IPv4&IPv6
DHCP Server, DHCP Relay, DNS, DDNS
NAT, NAPT

Routing

VPN Passthrough

  PPTP/L2TP/IPSec Passthrough

Data Usage Statistics

Firewall:

  Port Forwarding, DMZ, URL/Domain Blocking, MAC/IP/Port filtering, White/Black List

Device Management

  WEB, TR069



Environment

Dimension: 160mm*86mm*215mm
Net Weight 600 g

Color: Black or White

±8KV ESD Protection
Power Supply: 12V/2A
Operation Range: -10° to 55°C
Humidity:10-90% non-condensing

Installation: Desktop
