Tobee 16/14TU-AHR Rubber Lined Slurry Pump is end-suction, split-case, centrifugal slurry pumps that have set the world standard for heavy duty abrasive pumping applications. with large shaft diameters, heavy duty bearing assemblies and robust slurry pumping capacity, 16/14 slurry pumps provide a cost-effective and ideal alternative to longer lead times and the difficulty associated with working with large multinational.

Design Features:



√ 16/14 TU AHR Pump wet parts are made of Rubber.

√ 16/14 TU AHR Pump bearing assembly use cylindrical structure, adjusting the space between impeller and front liner easily. They can be removed completely when being repaired. Bearing assembly use grease lubrication.

√ the shaft seal could use the packing seal, expeller seal and mechanical seal for all slurry pump.

√ the discharge branch can be positioned at intervals of 45 degrees by request and oriented to any eight positions to suit installations and applications at its working site.

√ There are the drive types, such as V belt drive, gear reducer drive, fluid coupling drive, and frequency conversion drive devices.

√ Wide performance, good NPSH and high efficiency.

√ the rubber lined slurry pump can be installed in multistage series to meet the delivery for long distance.

Tobee Rubber Lined Slurry Pumps Sealing Arrangement:



Packing Seal

as one of the most commonly used seals for rotating shafts, the packing seal can come with low-flush or full flush arrangement which uses flushing water to prevent media from escaping the pump housing. this kind of seal is suitable for use under all pumping conditions. In situations where corrosive solids or high temperature might be encountered, Teflon or aramid fiber is used as the packing material for the gland. for High abrasion conditions, a ceramic shaft sleeve is available.



Centrifugal Seal - Expeller

the combination of impeller and expeller creates the pressure needed to seal against leakage. Together with the gland seal or lip seal which is used as the shut-down seal, this type of seal can handle sealing requirements for applications where full-flush gland seal is impractical due to lack of water on the site, or sealing water is allowed to enter inside the pumping chamber to dilute the slurry.
