Dewatering Principle

the screw press sludge dewatering machine a filter device formed by stacking a fixed ring and a moving ring, and the screw shaft penetrates through it. the front section is the concentration section, and the rear section is the dewatering section.

the filter slit formed between the fixed ring and the moving ring and the pitch of the screw shaft gradually decrease from the concentration part to the dewatering part.

while the rotation of the screw shaft pushes the sludge from the thickening section to the dewatering section, it also continuously drives the traveling ring to clean the filter gap to prevent clogging.



Usage



It can be widely used for sludge dewatering in various industries such as municipal sewage, food

Beverages, slaughter and breeding, printing and dyeing, petrochemicals,paper-Making, leather,

Pharmaceuticals, etc.

Main Advantages:





1. the moisture content of the sludge after dehydration is in the range of 75%-85%.

2. No filter cloth, self-cleaning, no clogging, no need for high-pressure back-Washing water.

3. Low speed operation, low energy consumption and low operating cost.

4. Few vulnerable parts, low maintenance cost and long service life.

5. Fully automatic control, continuous operation, simple maintenance and management.

Technical details:

 Formed by stacking a fixed ring and a moving ring, and the screw shaft penetrates through it. the front section is the concentration section, and the rear section is the dewatering section.



Our Factory:

Natin Environmental Protection Technology Co., Ltd is located in Chengdu, the historical and cultural capital of China. Which is a professional environmental protection equipment manufacturing and engineering service enterprise integrating technology research and development, manufacturing, installation and commissioning services, including municipal, paper-making, petrochemicals, food, and pharmaceuticals., slaughter, textile printing and dyeing, domestic sewage and etc. the main products include screw press sludge dewatering machine, auto dosing device, grille decontamination machine, dissolved air flotation machine, water filtration equipment, internal and external water rotary drum filter and other equipment.

  Model

Model	DS/KG	Motor power	10000mg/L	20000mg/L	30000mg/L	40000mg/L
NTDL131	5-10	0.36KW	~0.6m3/h	~0.33/h	~0.263/h	~0.253/h
NTDL132	10-20	0.54KW	~0.9m3/h	~0.63/h	~0.53/h	~0.43/h
NTDL201	10-18	0.92KW	~0.9m3/h	~0.63/h	~0.53/h	~0.43/h
NTDL251	15-30	0.92KW	~1.8m3/h	~1.13/h	~0.83/h	~0.73/h
NTDL252	30-60	1.47KW	~4m3/h	~2.53/h	~23/h	~1.53/h
NTDL301	30-60	1.3 KW	~4m3/h	~2.53/h	~23/h	~1.53/h
NTDL302	60-120	2.05KW	~8m3/h	~53/h	~43/h	~33/h
NTDL303	90-180	3 KW	~12m3/h	~7.53/h	~63/h	~4.53/h
NTDL351	50-100	1.85KW	~8m3/h	~43/h	~3.53/h	~33/h
NTDL352	100-200	2.95KW	~16m3/h	~83/h	~73/h	~63/h
NTDL353	200-360	4.4KW	~24m3/h	~123/h	~10.53/h	~93/h
NTDL401	80-160	3KW	~12m3/h	~63/h	~53/h	~43/h
NTDL402	160-320	4.5KW	~24m3/h	~123/h	~103/h	~83/h
NTDL403	240-480	7.5KW	~36m3/h	~183/h	~153/h	~123/h
NtDL404	320-640	9KW	~48m3/h	~243/h	~203/h	~163/h



FlowChart
