| Brand Name: | Partaker |
|---|---|
| Hard Drive Capacity: | 60GB |
| Screen Size: | No Monitor |
| Type: | Desktop |
| Products Status: | Stock |
| Place of Origin: | China (Mainland) |
| Model Number: | B5 |
| Processor Main Frequency: | 2.08 |
| Optical Drive Type: | |
| Display Type: | |
| Graphics Card Type: | Integrated Card |
| Processor Brand: | Intel |
| Processor Model: | N3150 |
| Processor Main Frequency: | 2.08Ghz |
| Lan Ports: | 2 LAN Ports |
| Feature: | Fanless System 0.00dB |
| Intel Celeron Processor N3150: | 2M Cache, up to 2.08 GHz |
| Case: | Brushed Alloy Case, 16*12*3.7CM |
Quick Details
Specifications
Model Number:Partaker B5
Color:Silver
Material:Aluminum
CPU:Intel Celeron Processor N3150/N3160/J3160 (2M Cache, up to 2.08 GHz) (CPU for random ship)
Graphics:Intel HD Graphics
Memory:1* so-DIMM DDR3L-1600, max. 8GB RAM
Storage:1* Msata SSD+1* 2.5 Inch HDD
Expansion:1 * MSATA3.0, 6Gb/s; 1 * SATA3.0, 6Gb/s+ 1 * MSATA SSD, 1 * WiFi module
Audio Cards:6-channel sound with ALC892 chip
Network Card:RTL8168/8111/8112 PCI-E 10/100/1000 Gigabit Ethernet NIC
WiFi:with dual antennas, 802.11.B/g/n, Built-in module with external antennas for boosting signal
Bluetooth:Optional (Default without this function, please do need to leave us message on the order, thank you)
I/0 Port:2*LAN+ 2*HDMI+ 4*USB 3.0+ 2*USB2.0+ Mic+ Spk
Power:DC100-240V AC/50-60Hz, DC 12V/3A
Operating Temperature:0°C~70°C Centigrade (32°F~140°F)
Storage Temperature:-20°C~80°C Centigrade (-68°F~176°F)
Relative Humidity:10%~90% (non-condensing)
Mini PC Stand:Yes
Vesa Mount:Optional
Weight:1.5kgs
Measurement:160*120*37mm
Consumption:6W
Motherboard Design:Fanless
Function:1. Support diskless boot
2. Support power-on (Restore AC Power Loss)
3. Support RAID0
Warranty:3 years
System Support:Windows 10,Linux Ubuntu,Vxworks etc;
System Default Option:Windows 10 pro as the default option;
ATTENTION:Barebone, Single RAM, Single SSD or SSD+HDD without any system.
Linux ubuntu or other OS, Do need to leave us message on the order, thank you.
Audio Cards:6-channel sound with ALC892 chip
Network Card:RTL8168/8111/8112 PCI-E 10/100/1000 Gigabit Ethernet NIC
WiFi:with dual antennas, 802.11.B/g/n, Built-in module with external antennas for boosting signal
Bluetooth:Optional (Default without this function, please do need to leave us message on the order, thank you)
I/0 Port:2*LAN+ 2*HDMI+ 4*USB 3.0+ 2*USB2.0+ Mic+ Spk
Power:DC100-240V AC/50-60Hz, DC 12V/3A
Operating Temperature:0°C~70°C Centigrade (32°F~140°F)
Storage Temperature:-20°C~80°C Centigrade (-68°F~176°F)
Relative Humidity:10%~90% (non-condensing)
Mini PC Stand:Yes
Vesa Mount:Optional
Weight:1.5kgs
Measurement:160*120*37mm
Consumption:6W
Motherboard Design:Fanless
Function:1. Support diskless boot
2. Support power-on (Restore AC Power Loss)
3. Support RAID0
Warranty:3 years
System Support:Windows 10,Linux Ubuntu,Vxworks etc;
System Default Option:Windows 10 pro as the default option;
ATTENTION:Barebone, Single RAM, Single SSD or SSD+HDD without any system.
Linux ubuntu or other OS, Do need to leave us message on the order, thank you.
