Highlights

Support WAN of xDSL, LTE and Ethernet

Dual Band WiFi: 2.4GHz + 5GHz

Fail over between WANs of xDSL, LTE and Ethernet

VPN: L2TP, IPSec, GRE

Support Static Route, OSPF, BGP, RIP and VRRP

Support VoIP (Optional)

Interface:

1 x RJ11 for ADSL2+/VDSL

1 x 10/100/1000Mbps WAN Port

4 x 10/100/1000Mbps LAN Ports

Dual Band WiFi: 2.4GHz + 5GHz

1 x SIM Slot

2 x LTE Antenna

2 x WiFi Antenna

1 x Rj11 for VoP(Optional)

1 x Power Supply

Buttons

Power on/off Button, WPS Button, WiFi Button, Reset Button



Data Functions

ADSL2+/VDSL2

  VDSL2 Profile: 8a/b/c/d, 12a/b, 17a, 30a and 35b

  ADSL2+ Annex A,B

  up to 8 VCs

LTE

  Cat 4, Max 150Mbps(DL)/50MBps(UL)

  Frequency Band:

  LTE: 1/3/7/820/38/40/41

  WCDMA: 1/8

  (Please contact us for more frequency band combinations)

Link Management

  Configurable Main Link and Back Link

  Link Detection

  WAN Fail over

WiFi

  IEEE 802.11b/g/n, 2.4GHz and 5Ghz (optional)

  Max Rate:300Mbps@WiFi N, 866Mbps@WiFi AC (optional)

  Antenna:2 x 5dBi dual band fixed antennas

WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption

DHCP Server/Relay, DNS, DDNS

Static Route, OSPF, RIP, BGP, VRRP

VPN: L2TP, IPSec, GRE

802.1Q/VLAN, IP Passthrough

Quality of Service (QoS)

Firewall, DMZ, Port Forwarding



Voice Features (Optional)

SIP (RFC3261), ITU-T G.729/G.722/G.711a/G.711

 Call forwarding, Call waiting, Call block, 3-way conference call, etc.



Environmental

Size: 210mm x 150mm x 30mm

Net Weight: 400g

Power Supply: DC12V/1.5A

Operation Range: 0℃ to 55℃

Humidity: 10%-90% non-condensing
