Highlights

DSL or Ethernet WAN Uplink

Dual WLAN WiFi N+AC

Excellent VDSL2/ ADSL2+ high speed

USB Port for Storage Sharing, Printer Sharing, FTP Server and Media Server

Easy Setup Assistant provides quick & hassle free installation

General

Interface:

1 x DSL Port

1 x 10/100/1000Mbps WAN Port

4 x 10/100Mbps LAN Ports

1 x USB2.0 port(option )and 1 x USB 3.0 port (option)

2 x Analogy Ports FXS (VoIP)

Buttons

Power on/off Button, WPS Button,

 WiFi Button, Reset Button



Data Functions

WAN Type: ATM/PTM/ETH/Dongle

DHCP

Server, Client, DHCP Client List,

 Address Reservation

Quality of Service (QoS)

WMM, Bandwidth Control

Port Forwarding:

Virtual Server, Port Triggering,

UPnP, DMZ

Networking Protocols

TCP/IP(IPv4/IPv6), UDP, RTP, SNTP, NAT, DHCP, DNS, DDNS

USB Sharing:

Support Samba(Storage)/FTP Server/

Media Server/Printer Server/DLNA



WiFi

IEEE 802.11b/g/n, 2.4GHz and 5Ghz

Max Rate:

300Mbps WiFi N

  866Mbps WiFi AC

Antenna:

2 x 5dBi dual band fixed antennas

WEP, WPA / WPA2, WPA-PSK/ WPA2-PSK encryption



Firewall & Security

Firewall Protection: DoS, SPI FirewallIP Address Filter/MAC Address Filter/Domain FilterIP and MAC Address Binding

Access control: Parental Control, Local Management Control, Host List, Access

Schedule, Rule Management

VPN: L2TP, PPTP, IPSec



Management

Management Protocol

Access Control

Local Management

Remote Management



Environmental

Size: 223mm x 150mm x 30mm

Net Weight: 400g

Power Supply: DC12V/1.5A

Operation Range

0℃ to 45℃, -32℉ to 113℉

Humidity: 10%-90% non-condensing
