Model Number: | Rph1/160 |
---|---|
Brand Name: | KS |
Place of Origin: | China (Mainland) |
Dimensions (L x W x H) (mm): | 800*800*640 |
Material: | QT400-15,QT450-10,QT500-7,QT600-3,QT700-2,ZG25,ZG35,ZG45 |
Type: | Tie Plates |
Type: | Sand casting, Hot Forging |
Quick Details
Specifications
Tie plates:
Railway tie plate, tie plate, Base plates, Insulator railway rubber pads, rail pads
Type: single shoulder, double shoulder, rolled, machined, forged or casted
Material: heavy hot-rolled steel
Size:5 1/2" (7 3/4*12" ),6"Technical Parameter
Type |
Dimension |
Holes |
Incline |
Rail |
Weight(Kg) |
Rph 1/160 |
345/285/127/160x15/13 |
? 26 (4x) |
1:40 |
S 49/S 54 |
7,86 |
Rp 01/01/160 |
345/285/127/160x15/13 |
? 26 (4x) |
1:40 |
S 49/S 54 |
7,70 |
Rph 1/210 |
345/285/127x210x15/13 |
? 26 (4x) |
1:40 |
S 49/S 54 |
10,55 |
Rph 1/210 |
345/285/127x210x15/13 |
? 36,3 (2x) |
1:40 |
S 49/S 54 |
10,55 |
Rph 1/210 FVZ |
345/285/127x210x15/13 |
? 26 (4x) |
1:40 |
S 49/S 54 |
10,69 |
Sph 1(a) |
345/350/127x410x15/13 |
? 26 (8x) |
1:40 |
UIC 60 |
20,60 |
Rph 6/160 |
370/310/152x160x15/13 |
? 26 (4x) |
1:40 |
UIC 60 |
8,44 |
Rph 6/210 |
370/310/152x210x15/13 |
? 26 (4x) |
1:40 |
UIC 60 |
11,32 |
SZ 60 |
370/350/152x420x15/13 |
? 26 (8x) |
1:40 |
UIC 60 |
22,73 |
Rph 11 ü |
664/554x160 |
? 26 (4x) |
1:40 |
S 54 |
15,37 |
Rph 13 ü |
690/570x160 |
? 26 (4x) |
1:40 |
UIC 60 |
15,27 |
Rpo 5 |
345/285/127x160x15/13 |
? 26 (4x) |
1:20 |
S 49/S 54 |
8 |
