| Brand Name: | JINPAT |
|---|
Quick Details
Specifications
Description
Product display
Notes:
We can not display more information on the website for sake of keeping trade secrets. Please send your request for more solutions to us via email
please contact us for your special needs so that our engineers provide the suitable solution and recommendation for you!
The 50mm unobstructed through-bore provides routing space for hydraulics, pneumatics or for a concentric shaft mount. The LPT050 uses our fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact force per fiber and low contact wear rates.
Features:
◆ 50 mm through-bore
◆ Compact 119mm outside diameter
◆ Modular design - a single module can have: one 50 amps ring; two 30 amps rings; one, two or three 10 amps rings or six 5 amps signals
◆ Up to 20-50 amps circuits
◆ Speed up to 500 rpm continuous
◆ Steel bearings and machined shaft and housing for harsh environment
◆ Collar mounting is standard; flange mounting is optional
◆ Various lead exits are available
|
Specification |
|
|
Circuits |
1-24 circuits |
|
Operating Speed |
0-500rpm |
|
Working Temperature |
-20℃~ +60℃ |
|
Working Humidity |
60%RH or higher |
|
Electrical: |
|
|
Voltage Rating |
380VAC/DC or higher |
|
Current Rating |
2A/5A/10A/15A per circuit |
|
Dielectric Strength |
≥1000V@50Hz between each circuit |
|
Insulation Resistance |
1000MΩ@ 500VDC |
|
Electrical Noise |
1mΩ Min |
|
Mechanical: |
|
|
Contact Material |
Precious metal |
|
Lead Wire Length |
Standard 300mm (11.811inch) |
|
Housing Material |
Aluminum alloy |
|
Torque |
≤9.25 g·m (for reference ) |
|
Protection |
IP54 or higher |
