| Pixels: | 4.81mm |
|---|---|
| Display Function: | Video |
| Tube Chip Color: | Full Color |
| Usage: | Indoor |
| Brand Name: | Beacon |
| Screen Dimension: | depend on customers' request |
| Place of Origin: | China (Mainland) |
| Pixel pitch(mm): | 4.81 |
| Pixel configuration: | SMD2121 1R1G1B 3 in 1 Black LED |
| Pixel density(dots/sq m): | 43264 |
| Calibrated brightness(CD/sq m,nit): | 1600 nits(adjustable) |
| Calibrated brightness proportion ratio: | R:G:B = 3:6:1 |
| Contrast ratio: | 4,500:1 |
| Brightness adjustment(dimming): | 100 grade auto/manual-adjustment |
| Color capability: | 4.4 trillion |
| Refresh rate(Hz): | >800 Hz |
| Frame frequency(Hz): | >60 Hz |
Quick Details
Specifications
Pixel configuration |
SMD2121 1R1G1B 3 in 1Black LED | ||
LEDs configuration |
Red:wave length: 615~625nm;130mcd | ||
Pixel pitch(mm) |
4.81 | ||
Pixel density(dots/sqm) |
43264 | ||
Calibrated brightness(CD/sqm,nit) |
1600 nits(adjustable) | ||
Calibrated brightness proportion ratio |
R:G:B = 3:6:1 | ||
Contrast ratio |
4,500:1 | ||
Brightness adjustment(dimming) |
100 grade auto/manual-adjustment | ||
View angle(degree)(50% brightness) |
V140/H140 | ||
Color capability |
4.4 trillion | ||
Refresh rate(Hz) |
>800 Hz | ||
Frame frequency(Hz) |
>60 Hz | ||
Interface port |
DVI interface(DVI connector) | ||
Input signal |
VGA, Video, AVI, MOV, MPG, DAT, VOB etc. | ||
LED Drive |
Constant-current drive | ||
Lifetime(hours)(50% brightness) |
100,000 hours | ||
Signal transmission direction |
Horizontal | ||
Operating temperature(Celsius degree) |
-20 ~ 60 | ||
Storage temperature(Celsius degree) |
-30 ~ 80 | ||
Operation humidity(RH) |
10-95% | ||
Operation humidity(RH) |
10-99% | ||
Servicice |
Front and back service optional | ||
Control mode |
Synchronous & asynchronous available | ||
Communication options |
Wire Ethernet, Fiber Ethernet,RF wireless,GPRS | ||
Power |
120/240 VAC single phase(50-60Hz) | ||
Maximum power consumption(W/sqm) |
1200 | ||
Average power consumption(W/sqm) |
400 | ||
Screen operation mode(scan/static) |
1/13 | ||
Cabinet configuration |
Length |
104 | |
Height |
104 | ||
Cabinet dimensions(mm) |
Length |
500 | |
Height |
500 | ||
Width |
85 | ||
Recommend Optimal Viewing Distance: Minimum & Maximum |
Min |
5 | |
Max |
100 | ||
Aspect Ratio(L:H) |
4:3 or 16:9 | ||
Packaging configuration |
5 standard cabinets in a flight case | ||
Packing material |
Flight case | ||
Packing weight(KG) |
net |
8KG/cabinet | |
gross |
9KG/cabinet | ||
