| Brand Name: | Ecoo-TSR |
|---|---|
| Type: | CTP Plate |
| Material: | Aluminum |
| Use: | Offset Printing |
| Usage: | Newspaper or commercial printing |
| Place of Origin: | China (Mainland) |
| Exposure Energy: | 120-150mj/cm2 |
| Resolution: | 1-99%@400lpi |
| Run-length: | 300,000 unbaked |
| Run-length for UV ink: | 100,000 |
Quick Details
Specifications
Double Layer Positive thermal CTP plate:Ecoo-TSR
1) Application: commercial color printing
2) Type: infrared sensitive, positive acting
3) Substrate: EC grained, anodized and PAT treated aluminum
4) Exposure energy: 120-150mj/cm2
5) Spectral sensitivity: 830nm
6) Resolution: 1-99% 400lpi / 10u FM
7) Run length: long, 400,000+ without baking; 100,000 for UV ink
8) Working environment: ordinary indoor white light
9) Developer: Kodak and Agfa developer(Fuji developer is not available)
2) Type: infrared sensitive, positive acting
3) Substrate: EC grained, anodized and PAT treated aluminum
4) Exposure energy: 120-150mj/cm2
5) Spectral sensitivity: 830nm
6) Resolution: 1-99% 400lpi / 10u FM
7) Run length: long, 400,000+ without baking; 100,000 for UV ink
8) Working environment: ordinary indoor white light
9) Developer: Kodak and Agfa developer(Fuji developer is not available)
10)Developing time and temperature:25s-35s,23±2°c
* Run length is always dependent on exposure, processing and press conditions.
Properties:
1. Easy-to-use
Able to work under white light; Wide latitude and excellent reliability
2. High resolution
Special ingredients, together with the optimally distributed formula weight of binding polymers, in the coating of KTP offer fine dots with sharp edges and reproduceimages with rich tone
3. Consistency
Computerized equipments on our production lines monitor over 50 production parameters to ensure batch-to-batch consistency
4. Cost-effective
the high sensitive coating of the plate extend the laser life of plate setter,speed up the exposure process without pre-heating; keep the run-length longer
5) Excellent hydrophilicity:
Multi-grains and hydrophilic treatment (PAT treatment) provides excellent water retaining capability at the non-image area, and thus keep ink-water balance optimally
6) Available sizes:
A) Width: 120 - 1,030mm
B) Length: 210 - 1,600mm
C) Thickness: 0.14 - 0.30mm
D) Other sizes available on request
* Run length is always dependent on exposure, processing and press conditions.
Properties:
1. Easy-to-use
Able to work under white light; Wide latitude and excellent reliability
2. High resolution
Special ingredients, together with the optimally distributed formula weight of binding polymers, in the coating of KTP offer fine dots with sharp edges and reproduceimages with rich tone
3. Consistency
Computerized equipments on our production lines monitor over 50 production parameters to ensure batch-to-batch consistency
4. Cost-effective
the high sensitive coating of the plate extend the laser life of plate setter,speed up the exposure process without pre-heating; keep the run-length longer
5) Excellent hydrophilicity:
Multi-grains and hydrophilic treatment (PAT treatment) provides excellent water retaining capability at the non-image area, and thus keep ink-water balance optimally
6) Available sizes:
A) Width: 120 - 1,030mm
B) Length: 210 - 1,600mm
C) Thickness: 0.14 - 0.30mm
D) Other sizes available on request
