| Brand Name: | Ecoo |
|---|---|
| Type: | CTCP Plate |
| Material: | Aluminum |
| Use: | Offset Printing |
| Usage: | Commercial or Newspaper printing |
| Model Number: | Ecoo-CTCP ED |
| Place of Origin: | China (Mainland) |
| Style: | Positive |
| Plate type: | Positive working |
| Run length: | 80,000-100,000 |
| Run length for UV ink: | 50,000-80,000 |
| Coating Color: | Blue |
| Exposure Energy: | 50-70mj/cm2 |
| Resolution: | 2-99%@200lpi |
Quick Details
Specifications
Double layer UV-CTP OFFSET PLATE(Positive CTcP plate)
UV-CTP plate, also known as the CTcP plate(computer to conventional plate), can also use the conventional PS plate with the UV setter. It is cost effective and easy to use.
Model: Ecoo-CTCP-D
Application: UV-CTP plate, applied to a variety of commercial printing and newspaper environment
Sensitivity: 50-70mj/cm2
Resolution: 2%@200lpi and 20u FM
Run-length: 50,000 for UV ink
Developing tolerance: Good
Developer: any developer for positive CTCP plate
Developing time and temperature: 25-30s, 23± 2° c
IPA Resistence: Good
Coating: Blue
Hydrophilic treatment: Yes
