this C-Type series unsealed thin section ball bearing is made from 52100 steel and utilizes a snap-over cage design made of brass or composite material. this bearing is designed for applications with primarily radial loads, and is manufactured to ABEC 1F precision tolerances.

Specifications
Product Category:Radial Ball Bearings

Type:Conrad / Deep Groove Thin-section

Application:Aerospace; Airframe / Aircraft Control; Instrument / Miniature; Medical / Dental; Military; Radar, Scanning Equipment, etc

Dimensions
Design Units:Inch
Bore:9.0000 inch (228.600 mm)
Outside Diameter:9.7500 inch (247.650 mm)
Width:0.3750 inch (9.525 mm)
Overall Width:0.3750 inch (9.525 mm)

Load Ratings
Static Axial:6470 lbs (2934 kg)
Static Radial:3230 lbs (1465 kg)
Dynamic Axial:5020 lbs (2277 kg)
Dynamic Radial:1730 lbs (785 kg)

Speed Ratings:Oil 2130 rpm

Bearing Class:ABEC 1 / Class 0 / P0; ABEC 3 / Class 6 / P6 (optional feature); ABEC 5 / Class 5 / P5 (optional feature); ABEC 7 / Class 4 / P4 (optional feature)

Material / Plating:Stainless Steel (optional feature); Ceramic Balls (optional feature); Corrosion Resistant (optional feature)

Seals / Shields:None (Open Bearing)

Features:Prelubricated; Solid Lubrication (optional feature); Flanged (optional feature); Snap Ring / Snap Ring Groove (optional feature)

Operating Temperature:-65 to 250 F (-54 to 121 C)
