| Feature: | Tower Crane |
|---|---|
| Certification: | iso, ce, gost |
| Brand Name: | HYCM |
| Max. Lifting Height: | 180M |
| Max. Lifting Load: | 16T |
| Condition: | New |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Warranty: | 12 Month |
| Model Number: | TC7040 Tower Crane |
| Place of Origin: | China (Mainland) |
| Span: | 3-70m |
| Rated Lifting Moment: | 3150kn.m |
| Rated Loading Capacity: | 16t |
| Application: | Large Buildings |
| Control system: | VFD inverter |
| Color: | Yellow, orange, green or according to client's needs |
| Type: | Yellow, orange, green or according to client's needs |
| Power supply: | 380V/50Hz, 415V/50Hz, 220V/50Hz or according to clients need |
| Electric box: | Schneider Contactor |
| Foundation type: | fixing angle |
Quick Details
Specifications
Model |
TC7040 Tower Crane | |
Type |
Fixed with outside climbing of buildings | |
Working Radius (m) |
70 | |
Max. Load Capacity (T) |
16 | |
Tip Load (T) |
4.0 | |
Free standing height (m) |
48 | |
Max. Height with anchorages (m) |
180 | |
Mast Section dimension (m) |
223, Angle steel 20026mm | |
Hoisting Mechanism
|
Speed (m/min) |
0-60 0-30 |
Motor power (kw) |
45 | |
Slewing Mechanism
|
Speed (r/min) |
0-0.6 |
Motor power (kw) |
2*5.5 | |
Trolleying Mechanism
|
Speed (m/min) |
0-60 |
Motor power (kw) |
5.5 | |
Jacking-up System
|
Speed (m/min) |
0.4 |
Motor power (kw) |
5.5 | |
Total Power (kw) |
61.5 | |
Power Supply |
380V/50Hz, 220V/60Hz or others | |
Introduction
HYCM Crane is a professional manufacturer and exporter of tower crane and
Construction hoist in China, owning CE and ISO certificates, with high quality products and competitive price.Our items are praise with good quality and excellent after-sale service.
with more than 15 years experience, our products has exported to many countries, such as Vietnam, the Philippines, India, and Algeria, etc.
What's more, we have two factories which are located in Jinan City, Shandong Province, in north side of China. with convenient communications, we're not far away from Qingdao port.
