Main Features

     Max 350W Electrosurgical Generator, with mono-polar and bipolar function.

     Six working modes: pure cut, blend1, blend2, contact coag, forced coag, bipolar coag.

     Wide clinical applications, such as the general surgery, thoracic surgery, orthopedic surgery, cardiology, gynecology, urology(under water TUR), oncology, neurosurgery, etc.

     Microprocessor controlled, digital display. with audible and visual indicators and errors codes during the process of outputting.

     Return Electrode Monitoring system and Power Peak System, minimizing the risk of tissue damage.

     both hand and foot controlled.

     Separate power display and outlet socket for mono-polar cut, mono-polar coag, bipolar cut and bipolar coag, each output can be individually configured.

     the unit always remember the last setting when it turned off.

     Remote control function. the surgeon can adjust the outputs by power control ESU pencil.

     the ESU unit can be connected with laparoscope and endoscope, etc.

     Protection against over-voltage and over-current.

     Defibrillation protected.

     Mounted on a 4 wheels cart(optional).

     Meets the requirements of international safety standards EN60601-1 and EN60601-2.



Technical Specifications

Power: 220V22V, 50Hz1Hz(110V11V, 60Hz)

Operating frequency: 512KHz

Power rating: 1100VA10

Six working modes:

Mono-polar Cut

A) Pure cut: 1W350W( Load 800)

B) Blend1: 1W200W(Load 800)

C) Blend2: 1W250W(Load 800)

Mono-polar Coag

D) Spray Coag: 1W80W( Load 800)

E) Forced Coag: 1W120W( Load 800)

Bipolar

F) Bipolar Coagulation: 1W70W( Load 200)

Power Consumption: 1100VA
