Main Features

Microcomputer Control, can be controlled by hand or by foot.

the generator adopts LEEP Which specializing in gynecological intrauterine event, increasing the Accuracy, controllability, security of the surgery.

Dealing with some Kinds of pathological changes in obstetric and gynecology,   for example, cutting, electrocoagulation, Cervical erosion, and some kinds of surgery that fit in peritoneoscope.

Different electrodes have Different effects in coagulation.

An optional smoke Evacuation system is available.

Paticular illuminating ESU pencil can Increase the clarity of wound healing.

Technical Specifications

Power: 220V22V(110V11V), 50Hz1Hz

Power Rating:1100VA10

Ralated power output

Function	Working modes	Power output (Max)	load	Frequency
Monopolar Cut	Pure Cut	200W	800	416HKz
	Blend1	150W	800
	Blend2	100W	800
Monopolar Coagulation	Spray	80W	800
	Forced	120W	800



Surgical Smoke Evacuation Parameter

Blowing Rate	100 l/min @6mm tube
Start Control	Manus/Foot/Synchronize
Suction Adjust	10%100%
Stop Delay time	060s
AC Power	AC90~250V, 50Hz
Power Consumption	< 350W
Filter Characteristics	99.999% @ 0.1-0.2m
Active Carbon	97% @ 1 year



 Packing List

Accessory Name	Quantity
Main Unit	1set
Electrosurgical Pencil	5pcs
Electrosurgical Pad	10pcs
Electrosurgical Pad cable	1pc
Footswitch	1set
Tip Clean Sponge	1pc
Electrodes	10pcs
Vaginaldilator	1set
SurgicalSmoke Evacuation	1set
Trolley	1set
