| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Certification: | ISO,CE |
| Overall Dimensions: | 2060*1086*2115MM |
| Fork Width: | 100mm |
| Fork Length: | 1070mm |
| Min. Lifting Height: | 3000mm |
| Max. Lifting Height: | 60mm |
| Rated Loading Capacity: | 1500kg |
| Power Souce: | DC Motor |
| Type: | Powered Pallet Truck |
| Model Number: | CPD15C |
| Brand Name: | Wecan |
| Place of Origin: | China (Mainland) |
| Condition: | New |
Quick Details
Specifications
CPD15C Battery Powered Forklift Truck:
|
Model |
CPD15C |
|
|
Load capacity kg |
1500kg |
|
|
Load center mm |
500mm |
|
|
Power type |
Battery |
|
|
Max.lifting speeds |
285mm/s |
|
|
(with load)mm/s |
||
|
Max.Driving speeds |
12.5/14km/h |
|
|
(with without load)km/h |
||
|
Max.Towing speeds |
6.5kN |
|
|
(with load)kN |
||
|
Gradeability(with load)% |
15% |
|
|
Lifting height mm |
3000mm |
|
|
Free lift mm |
60mm |
|
|
Tilting angles |
6/12(forward-backward) . |
|
|
Min. turning radius mm |
1820mm |
|
|
Min. right angle aisle width mm |
1810mm |
|
|
Min. under-clearance mm |
95mm |
|
|
Dimensions |
A Overall length (inincluding fork) mm |
2960 |
|
B Overall width mm |
1086 |
|
|
H Overall height(mast lowered) mm |
2115 |
|
|
H2 Overall height(mast extend) mm |
4015 |
|
|
H3 Overall height to overhead guard mm |
2115mm |
|
|
B3 Fork width mm |
100mm |
|
|
H4 Fork thickness mm |
35mm |
|
|
A3 Fork length mm |
920(1070)mm |
|
|
A1 Fork overhang mm |
436mm |
|
|
A2 Wheel base mm |
1250mm |
|
|
Tread |
Front tread mm |
900mm |
|
Rear tread mm |
920mm |
|
|
Tyre |
Front tyre |
6.50-10mm |
|
Rear tyre |
5.00-8mm |
|
|
Total weight kg |
3050 |
|
|
Motor |
Traction motor |
XQ-5-4A3 |
|
Lifting motor |
XQD-7.5-3C |
|
|
Battery |
Battery type |
D-440 |
|
Battery voltage/Capacity V/Ah |
48/440 |
|
Packing details: 6 pcs/20'Container; 12 pcs/40'Container
