Marble Stone Engaving Machine CNC Engraver Cutter(NC-1325)

Features:
1. The integrally cast iron lathe bed is used for great solidity and stability.
2. Option metal tools are available to facilitate metal engraving
3. Wheels help you load stone board more easier.
4. Imported air-pressure controller and limited switch.
5. High-speed water cooling spindle, high performance subdivision driver.
6. Precise and efficient control system, coming with professional software.

Field of application:
3D engraving, line engraving, cutting, edge inversing, drilling on natural marble, granite, artificial stone, tombstone, milestone,
ceramic tiles, glass, metal, iron, steel and so on.
  Stone furniture: Stone table board, stone stage, stone washbasin/washbowl table/chair/bed, stone crafts, modeling stone etc.
  Building decoration supporting stone: Arch arch, stone railing, stone line, Mosaic/stone spelling flowers, stone fireplace,
carved stone pillars, stair/grain footsteps, stone censer, etc
  Cylinder stone processing: Columns, the Roman pillars, dragon post, hollow columns, the pillars, column cap, polished pillars,
new lines pillars.

Specifications:

NO.	Description	Parameter
1	X, Y, Z Working Area	1300x2500x300mm
2	Table Size	1560× 3000
3	Working Accuracy	< 0.05mm
4	X, Y, Z Traveling Positioning Accuracy	±0.03/300mm
5	X, Y, Z repositioning Positioning Accuracy	±0.05mm
6	Frame Structure	Welded Structure
7	X Y Z Guide Rail	High precision linear guide rail
8	X Y Transmission	Imported Rack Gears
9	Z Transmission	Imported Ball Screw
10	Max. Consume Power	5KW
11	Max. travel speed	0-32000mm/min
12	Max. Working Speed	0-20000mm/min
13	Spindle Power	3kw water-cooling spindle(Optional 5.5kw water-cooled spindle)
14	Water Tank/Pump	included
15	Spindle Speed	0-24000RPM
16	Cutting Tool Diameter	φ 3.175/4/6/8/10/12.7
17	Table	Aluminum T-Slot working table
18	Working Voltage	AC220V/50/60Hz, 1PH
19	Driving System	Stepper Motor
20	Format of Instructions	G code, *uoo, *mmg, *plt
21	Control system	English NC-studio
22	Software	Ucancam, Type3, Artcam
23	Interface	USB
24	Flash Memory	128M
25	Collet	ER25
26	Running circumstance	Temperature: 0 -45 degree Relative humidity: 30% - 75%
27	Packing Size	Separated: 3200X1950X1404mm Integrated: 3200X1950X1950mm
28	Net Weight	1000KG
29	Gross Weight	1200KG
All parameters above subject to change without prior notice
