| Brand Name: | SONOICARE |
|---|---|
| Type: | Ultrasound Scanner |
| Warranty: | 18 months |
| Portable: | laptop |
| Certification: | CE and ISO |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
MainFeatures:
Powerful measurement & calculation software packages
8-Segment TGC adjustment
7 kinds of pseudo-colors
12inch LCD monitor
OB measurements: BPD, GS, CRL, FL, AC, HC,etc
Back-lit keyboard
2 probe connectors
Main Technical Specification:
Scanning mode: Convex/Linear/Trans-vaginal
Display modes: B, B+B, B+M, M, 4B
Scanning depth: 240mm
Gray scales: 256
Body marks: 18
Image conversion: up/down, left/right, black/white
Function of puncture guide
Per: 4-stage per function
Printer function: can connect laser printer and Video printer directly
Comment: Date, Name, Sex, Age, Hospital, Annotation
Zooming: *0.8, *1.0, *1.2, *1.5, *2.0
Port: USB 2.0, VGA, Video connector
Wide application: abdomen, OB/GYN, urology, cardiology etc
USB Function of image store: more than Sixteen thousand images
Power supply: AC 110V-240V, 50HZ/60HZ
Probe connector: 2
Measurement:
General menu: Distance, Area, Volume, Angle, Ellipse
Obstetrics menu: GS, CRL, BPD, HC, AC, FL, Fetus Weight
Heart menu: Distance, Time, Slope, Rhythm
Standard configuration:
Main unit
12 inch LCD monitor
60R/3.5MHZ Convex array probe
USB 2.0, VGA port
Video connector
Battery
Options:
L40/7.5MHZ Linear array probe
20R/5.0MHZ Micro-Convex array probe
13R/6.5MHZ Trans-vaginal array probe
Video Printer and Laser Printer
