| Application: | Laser Engraving |
|---|---|
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | CE |
| Dimension(L*W*H): | 2000*1500*1000mm |
| Model Number: | NC-4060 |
| Brand Name: | NICE-CUT |
| Place of Origin: | China (Mainland) |
| Graphic Format Supported: | AI,BMP,DST,DWG,DXF,DXP,LAS,PLT |
| Applicable Material: | Acrylic,Crytal,Glass,Leather,MDF,Metal,Paper,plastic,Plexiglax,Plywood,Rubber,Stone,Wood |
| Cooling Mode: | Water Cooling |
| CNC or Not: | Yes |
| Engraving Speed: | 1200mm/s |
| Engraving Area: | 400*600mm |
| Laser Type: | CO2 |
| Condition: | New |
| Type: | CO2 Laser Engraving Machine |
Quick Details
Specifications
Laser engraving machine NC-E4060
Application:
Acrylic, double-color board, glass, crystal, marble, bowlder, ceramic, wooden products, bamboo, leather, cloth, plastic, paper, rubber, MDF, wooden board and other non-metal materials.
Advertising and signs, building decoration, arts and crafts, furniture, wooden package, toy, model, etc.
Special Features:
1, Advanced DSP control system, support working without the connection with PC.
2, Imported linear guide, ensure the high precision.
3, Dual protection. Not only the protection of watercooling system, but the protection of protect sensor, which protect laser tube under the condition of no water or water inadequate.
4, Three phase stepper motor, guarantee the machine running steadily, stable movement.
5, with function of restoring from power-off, continue working from break point.
Key Specifications:
|
Type
|
NC-E4060
|
|||
|
Engraving Area
|
400 x 600mm
|
|||
|
Laser Power
|
60W
|
|||
|
Laser Type
|
CO2 Laser Tube
|
|||
|
Engraving speed
|
0~1000mm/s
|
|||
|
Cutting speed
|
0~600mm/s
|
|||
|
Resetting positioning accuracy
|
0.01mm
|
|||
|
Cutting depth
|
depend on materials
|
|||
|
Minimum Shaping Character
|
1.5× 1.5mm
|
|||
|
Power supply
|
220V± 10% 50HZ or 110V± 10% 60HZ
|
|||
|
Gross power
|
1200W
|
|||
|
Software supported
|
ArtCut, CorelDraw, PhotoShop, AutoCAD
|
|||
|
Graphic format supported
|
PLT, DXF, BMP, JPG, GIF, PGN, TIF
|
|||
|
Engraver for Curve surfaces (Yes/No)
|
No (rotary attachment can be added for cylinders)
|
|||
|
Water Cooling: (Yes / No)
|
Yes
|
|||
|
Maximum Height of Materials to
Engrave (mm)
|
280mm(Up and down by motor)
|
|||
|
Laser Tube (life hours)
|
1000hours
|
|||
|
Assistant Equipment
|
Water pump
|
Exhaust Fan
|
Aluminum alloy worktable
|
|
|
Optional Spare Parts
|
RF Tube
|
Rotary System
|
Cooling water system
|
Red Dot Pointer
|
|
Recommended Spare Parts / Consumables
|
Laser Tube and Lens
|
|||
