Product Main

Quick Details

Type: Soldering Machine
Usage: Z
Dimensions: CZ
Voltage: ZC
Brand Name: eta
type: 2
After-sales Service Provided: Engineers available to service machinery overseas
Certification: ZC
Weight: CZ
Current: CZ
Rated Capacity: ZC
Rated Duty Cycle: CZ
Model Number: E10
Place of Origin: China (Mainland)
Condition: New

Specifications

Specifications
ETA-E8(8-Zone)
General
Outside Dimension(L*W*H)
4800x1250x1490mm
Standard Color
Computer Grey
Weight
Approx.2250KG
Number of Heating Zones
Up8/Bottom8
Length of Heating Zones
2900mm
Exhaust Volume
10M3/minx2 Exhausts
Standard Feature of Control System
Electric Supply Required
3phase,380V 50/60Hz
Power for Warm up
30KW
Power Consumption
8KW
Warming Time
Approx.20 minute
Temp. Setting Range
Room Temp. ---  300 centigrade
Temperature Control Method
PID Close Loop Control + SSR Driving
Temperature Control Precision
± 1.0 centigrade
Temperature Deviation on PCB
± 1.5  centigrade (by MR Board Test Standard)
Heating Element
Especial Heating elements for Long Life;
Commutated Element
Aluminium Alloy Plate
Max. Temp. Gap between Preheat & Reflow Setting
80 centigrade
Max. Temp. Gap between Preheat Zones Setting
40 centigrade
Max. Temp. Gap between Reflow Zones Setting
50 centigrade
Data Storage
Process Data and Status Storage
Abnormal Alarm
Abnormal Temperature (Extra-high / Extra-low Temp.)
Board Dropped Alarm
Tower Light: Yellow–Warming; Green-Normal; Red-Abnormal
Features of Conveyor System
Rail Number
1 Lane
Max.Width of PCB
320mm (Option:610mm )
Components Clearance
Top/ Bottom Clearance of PCB is 25mm
Converyor Direction
L→R (Option: R→L)
Fixed Rail Side
Front Rail Fixed(Option:Rear Rail Fixed)
Transmission Agent
Air-Reflow =  Chain + Mesh,    N2-Reflow=Chain(Mesh is option)
Center Support (Option)
Preventing PCB warp such too wide and heavy component load
Converyor Height
900+/-20mm
Converyor Speed Range
300-2000mm/min
Lubrication Auto-Afflux
Standard
Temp. Thermocouple Slot
Standard
Driven Top Hood Opening
Standard
on Line Editing
Standard
Cooling Method
Forced-Air   (Standard),             Water-Chiller (Option)
Model for Nitrogen Process
Power for Warm up
32KW
Power Consumption
12KW
Flux Management System
Flux Reclaimed and Filtration standard for N2Oven, easy clean-up.
N2 containment at Entry and Exit End
Standard
Flux Reclaim System
Standard
Nitrogen Flow Meter
Standard
Oxygen Analyser
Option
Nitrogen Consumption [Standard]
400~1000PPM 20M3/H
Water Chiller
3 ;  External Stand-alone Type;  Powerful Cooling suit to Lead-Free Process Required
