| After-sales Service Provided: | Overseas service center available |
|---|---|
| Condition: | New |
| Brand Name: | eta |
| Weight: | 2 |
| color: | grey |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Model: |
ETA-A800 |
No of heating zones |
UP8/Bottom8 |
Length of heating zones |
1900MM |
Heating method |
Hot air circulating |
No or cooling zone |
1 |
PCB width |
350MM |
Conveyor direction |
L→R or R→L |
Conveyor height |
880±20mm |
Conveyor method |
Mesh transmission |
Conveyor belt height |
0-1500mm/min |
Power supply |
5 line 3 phase 50/60Hz |
Power for warm up |
14KW |
Power Consumption |
4KW |
Warming time |
Approx 15 min |
Temp. Setting Range |
Room temp~300 |
Temp control |
Computer+PID Close Loop Control |
Temperature Control Precision |
±1 |
Temperature Deviation on PCB |
±2 |
Abnormal alarm |
Temperature anomaly |
Dimension(L*W*H) |
3600×720×1250mm |
Weight |
380kg |
ETA Electronic equipment CO.,LTD. to provide professional SMT automatic production line solution,the company specializes in SMT chip mounter(New:SM421,SM411,SM100 etc)(second-hand: CP40L; CP40LV; CP45F; CP45FV; CP45FVneo); YAMAHA SMT machine (YAMAHA Chip shooter); JUKI chip mounter,SIEMENS SMT machine,PANASONIC SMT Chip mounter, FUJI second-hand SMT machine.We are also sell printing machine,Point glue machine, Reflow soldering,Wave soldering,Automatic plug-in machines,SMT machine feida, Accessories,stencil printer,Reflow oven,flow welding,Panasert,AOI,X-ray,LED automatic die bonder etc,for communication products manufacturers,LED display, lighting manufacturers; SMT, AI materials processing, and other enterprises provide the required equipment or wiring scheme.
