| After-sales Service Provided: | Engineers available to service machinery overseas |
|---|---|
| Warranty: | ONE YEAR |
| Certification: | CE |
| Weight: | 160kg |
| Dimension(L*W*H): | 360*360*100mm |
| Power(W): | 1000W |
| Voltage: | 220V |
| Model Number: | NC-A3636 |
| Brand Name: | NICE-CUT |
| Place of Origin: | China (Mainland) |
| CNC or Not: | CNC |
| Condition: | New |
Quick Details
Specifications
NC-A3636 3d metal milling cnc router acrylic pcb engraving machine price
Wood Engraving CNC Router Features:
Wood Engraving CNC Router Features:
1The integrally cast lathe bed is used for great solidity and stabllity.
2. High precision makes it suitable for the arts and crafts advertising industry.
3. Option mental tools are available to facilitate mental engraving
4. High-speed water cooling spindle, high performance subdivision driver.
Applicable Industries
1. Wooden areas: mainly used in redwood classical and antique furnitures, wood carving, gifts wooden box, redwood jewelry boxes, ink-stone cutting, decorative products sculpture, fine jewelry carving.
2. Models: company plate, signs, building models, emblem, badge, display panels, fair signs, building numbers, signs of decoration, furniture and other decoration.
3. Other lines: also used in portraits, landscapes, calligraphy lettering, seal carving and other plane surface carving, basso-relievo.
Specification/Parameters:
|
NO.
|
Description
|
Parameter
|
|
1
|
X, Y,Z Working Area
|
360x360x100mm
|
|
2
|
Table Size
|
520X660mm
|
|
3
|
X, Y,Z Traveling Positioning Accuracy
|
± 0.03/300mm
|
|
4
|
X, Y,Z repositioning Positioning Accuracy
|
± 0.05mm
|
|
5
|
Lathe Structure
|
Cast Aluminum
|
|
6
|
X, Y Structure
|
Shaft Linear Bearings and Ball Screw
|
|
7
|
Z Structure
|
Ball Screw
|
|
8
|
Max. Consume power
|
3.0Kw
|
|
9
|
Max. Speed
|
0-5500mm/min
|
|
10
|
Max. Working Speed
|
0-3000mm/min
|
|
11
|
Spindle Power Motor
|
1.5kw water-coolant spindle
|
|
12
|
Spindle Speed
|
0-24000RPM
|
|
13
|
Drive Mode
|
Stepper Motor
|
|
14
|
Working Voltage
|
AC220V/380V, 50/60Hz
|
|
15
|
Command
|
G code, *uoo, *mmg, *plt
|
|
16
|
Operating System
|
DSP System
|
|
17
|
Interface
|
USB
|
|
18
|
Flash Memory
|
128M
|
|
19
|
Collet
|
ER18
|
|
20
|
X, Y Working Delicacy
|
< 0.01mm
|
|
21
|
Software
|
Type3, Ucancam, Artcam
|
|
22
|
Running circumstance
|
Temperature: 0° C~45° C Relative humidity: 30%~75%
|
|
23
|
Packing Size
|
910X880X800mm
|
|
24
|
Net Weight
|
100KG
|
|
25
|
Gross Weight
|
150KG
|
|
All parameters above subject to change without prior notice
|
||
1. Choice a suitable working area
Small size such as 600*600mm and 600*900mm is mainly used for duoble-color board and acrylic and the price of smaller is as much as the two models.
The large size of the machine such as: 1200*1200,1200*2400,1300*2500,2000*3000,2000*4000, it is mainly used for wood and pvc, the large size machine is suitable for engraving and cutting for large materials.
2. Choice a suitable spindle motor.
Spindle motor is one for important components for cnc router, the performance of cnc router put an important role in cnc router.
Q2: When the machine can' t work well, What should I do?
1. Engineer is online for 24-hours, they can check the problems and then give you a sulutions in two hours.
2. Our machine are with one' s year warranty, If any problems of machine parts under " normal use" , new machine parts will be sent by air In free.
3. Please rest assured that operation CD and manual will be offered along with machine, making you can operate the machine easily.
