| Condition: | New |
|---|---|
| Capacity (Load): | 1 - 10t |
| Drive Wheel: | 4x4 |
| Horsepower: | < 150hp |
| Transmission Type: | Manual |
| Emission Standard: | Euro 2 |
| Fuel Type: | Diesel |
| Engine Capacity: | < 4L |
| Size: | 6020x2080x2520 mm |
| Gross Vehicle Weight: | 9100 kg |
| Place of Origin: | China (Mainland) |
| Brand Name: | KAMA |
| Model Number: | KMC1060D3 |
Quick Details
Specifications
|
Cab |
|
|
Cabin |
one and half cab (1820) |
|
Seats in cabin |
3 |
|
Engine |
|
|
Model |
Diesel, 4102ZL(FAW), euro-2 |
|
Type |
in-line, water cooling, 4-stroke |
|
Power (kw) |
70.6 |
|
Rated rotate speed (r/min) |
3200 |
|
Bore/Stroke (mm) |
102x118 |
|
Displacement (liter) |
3857 |
|
Configurations |
|
|
Drive type |
4x4 |
|
Steering |
Left hand drive |
|
Transmission |
530 |
|
Clutch |
Single plate, Dry type |
|
Gearshift |
5+1 speed, manually |
|
Gearshift ratio |
6.802; 3.878; 2.267; 1.424; 1.000; 6.154 |
|
Front axle |
LS2080 drive axle |
|
Rear axle |
1080 air brake |
|
Final drive |
6.333 |
|
Brake system |
Air brake |
|
Parking brake |
Spring energy air cut brake |
|
Tyre |
8.25-16 |
|
Battery |
24V |
|
Power steering |
With |
|
MP3 |
with |
|
Parameters |
|
|
Load weight (kg) |
4T |
|
Curb weight (kg) |
4100 |
|
G.V.W |
9100 |
|
Overall size (mm) |
6020x2080x2520 |
|
Cargo body size (mm) |
3800x1900x390 |
|
Wheel base (mm) |
3300 |
|
Front/ Rear track (mm) |
1545/1515 |
|
Max. Speed(Km/h) |
80 |
