| Usage: | It's used for helmet surface friction testing |
|---|---|
| Power: | Electronic |
| Brand Name: | HOTOTECH |
| Warranty: | 2 year |
| weight: | 800 kg |
| Model Number: | +86-769-87925057 |
| Place of Origin: | China (Mainland) |
| product Name: | Projection and surface friction testing machine |
| Standard: | ECE R22.05 standard |
| The mass of drop weight: | 15kg |
| Drop height: | 500mm |
| Mass of loading system: | 400N |
Quick Details
Specifications
Projection and Surface Friction Testing Machine (HT-6013)
Projection and surface friction testing machine
Function and feature:
1. According to ECE R 22.05 standard.
2. Mass of drop weight: 15kg.
3.Drop height: 500mm.
4.Mass of loading system: 400N ( 40.8kg).
5. Electro-magnet controlled release system.
6. The lever guiding system, stick the abrading material onto its Outer surface, tangential to the test area of helmet.
7. Adjustable head form support.
8. Dimension of machine: 150cmX 60cmX150cm.
9. Electricity: 220V/50Hz.
10. Power: 200W.
Projection and surface Friction Testing Machine's picture
Projection and surface friction testing machine
Function and feature:
1. According to ECE R 22.05 standard.
2. Mass of drop weight: 15kg.
3.Drop height: 500mm.
4.Mass of loading system: 400N ( 40.8kg).
5. Electro-magnet controlled release system.
6. The lever guiding system, stick the abrading material onto its Outer surface, tangential to the test area of helmet.
7. Adjustable head form support.
8. Dimension of machine: 150cmX 60cmX150cm.
9. Electricity: 220V/50Hz.
10. Power: 200W.
Projection and surface Friction Testing Machine's picture
