Engine

Make

Caterpillar

Model

3406DITA

Net Power

323 hp

240.9 kw

Gross Power

300 hp

223.7 kw

Displacement

890.9 cu in

14.6 L

Operational

Operating Weight

65638.2 lb

29773 kg

Fuel Capacity

124.2 gal

470 L

Hydrauilc System Fluid Capacity

54.9 gal

208 L

Engine Oil Fluid Capacity

10 gal

37.9 L

Static Tipping Weight

44767.1 lb

20306 kg

Transmission

Number of Forward Gears

4

Number of Reverse Gears

4

Max Speed - Forward

23.2 mph

37.4 km/h

Max Speed - Reverse

26.6 mph

42.8 km/h

Hydraulic System

Raise Time

6 sec

Dump Time

2 sec

Lower Time

3.4 sec

Bucket

Breakout Force

47277 lb

 kN

Dump Clearance at Max Raise

10.7 ft in

3271 mm

Bucket Width

11.3 ft in

3447 mm

Bucket Capacity - heaped

5.5 yd3

4.2 m3

Dimensions

Length with Bucket on Ground

31.1 ft in

9465 mm

Width Over Tires

10.7 ft in

3250 mm

Height to Top of Cab

12.3 ft in

3750 mm

Ground Clearance

1.5 ft in

467 mm

Reach at Max Lift and Dump

5.1 ft in

1545 mm
