Specification:

HZS series concrete mixing station

HZS series of concrete mixing station for the second-stage automatic or semi-automatic concrete mixing plant,by mixing, ingredients, electronic control systems, powder storage silos, powder screw conveyor and other components.

Features

1. 1. Mixer host using JS series of dual-axis forced mixing host, mixing quality, high efficiency

2. Using modular structure, the whole machine installation, relocation convenience

3. Aggregates, powder, liquid materials and other ingredients are used electronic weighing quality, high precision ingredients

4. the main electronic control system uses imported electronic components, reliable performance, easy to operate

Specification

Model	HZS25	HZS30	HZS50	HZS75	2HZS25	2HZS35
Max. Productivity(m3/h)	25	30	50	75	50	70
Main mixer	JS500	JS750	JS1000	JS1500	2xJS500	2xJS750
Overload height(m)	1.6/3.8	3.8	3.8	3.8	3.8	3.8
Aggregate measurement accuracy(%)	2	2	2	2	2	2
Water measurement accuracy(%)	2	2	2	2	2	2
Concrete measurement accuracy(%)	1	1	1	1	1	1
Admixture measurement accuracy(%)	2	2	2	2	2	2
Max.Cement masurement weight(kg)	300	400	600	1000	2x300	2x400
Max. Agrregate measurement weight(kg)	1500	2000	3000	4000	1500	2000
Max. Water measurement weight(kg)	200	200	250	400	2x200	2x200
Max.Admixture measurement weight)kg)	40	40	40	50	2x40	2x40
Screw conveyor conveying capacity(t/h)	35	35	35	35	35	35
Silo capacity(t)	50	100	100	100	50	100
Machine power(kw)	60	70	100	110	110	130
Machine weight(t)	25	32	40	46	45	56

Photos for reference:
