| Bucket capacity: | 722kgs |
|---|---|
| Moving Type: | Crawler Excavator |
| Condition: | New |
| Brand Name: | SHMC |
| Year: | 2018 |
| Make: | XCMG |
| After-sales Service Provided: | Engineers available to service machinery overseas |
| Certification: | ISO |
| Rated Speed: | 4.2km/h |
| Max Digging Radius: | 1815mm |
| Machine Weight: | 7425kgs |
| Maximum Digging Depth: | 4140mm |
| Maximum Digging Height: | 5100mm |
| Operating Weight: | 7425kgs |
| Model Number: | XE80 |
| Place of Origin: | China (Mainland) |
Quick Details
Specifications
Specification:
|
Model |
Unit |
XE40C |
|
|
Operating weight |
kg |
7425 |
|
|
Standard bucket capacity |
m |
0.34 |
|
|
Standard bucket capacity |
mm |
722 |
|
|
Engine |
Engine Model: CumminisB3.3 |
||
|
Rated power/speed |
Kw/rpm |
60/2200 |
|
|
Main performance |
Travel speed |
km/h |
4.2/2.6 |
|
Swing speed |
r/min |
12 |
|
|
Max.Bucket digging force |
kN |
53.6 |
|
|
Fuel capacity |
Fuel tank capacity |
L |
135 |
|
Hydraulic tank capacity |
L |
70 |
|
|
Engine lubrication |
L |
7.4 |
|
|
Dimension |
Overall length |
mm |
6155 |
|
Overall width |
mm |
2220 |
|
|
Overall height |
mm |
2618 |
|
|
Overall width of upper structure |
mm |
1500 |
|
|
Track length |
mm |
2198 |
|
|
Overall width of undercarriage |
mm |
1635 |
|
|
Crawler width |
mm |
722 |
|
|
Dozer black(width/height) |
mm |
1650300 |
|
|
Working range |
Max. Digging height |
mm |
7167 |
|
Max. Dumping height |
mm |
5100 |
|
|
Max. Digging depth |
mm |
4140 |
|
|
Min. Swing radius |
mm |
1815 |
|
