Features:

Adopts original SONY CCD/CMOS chip or Micron CMOS chip, lossless image

Built-in double IR-CUT filter (only for CMOS chip), No color deviation

Adopts Long-life and SMART 3pieces Epistar IR Arrays, IR range up to 40meters

3.6mm high quality lens, 6mm,8mm and 12mm Optional

Support BLC  (backlight Compensation), auto white balance, color reproduction and high, less Noise,        illumination lower, more Stable performance

Adopts double glass, the image more clear and bright

Plastic housing

Specification:

Model

DLX-D3A10

Sensor

1/3" CMOS

Horizontal Resolution

1080TVL

Signal System

PAL/NTSC

Lens

Fixed focus 3.6mm lens (6,8,12mm optional)

Min. Illumination

0LUX(IR on)

IR

3pieces Epistar IR Arrays, IR range 40M

BLC

Auto

AGC

Auto

Electronic shutter

1/50(1/60)s to 1/100,000s

S/N

>52dB

Gamma correction

>0.45

Video output

1.0Vp- p75(BNC)

Power

DC12V 10%

Material

Plastic

Operating Conditions

-18 C - 50 C, Humidity 90% or less (non-condensing)

Dimension

90x80mm

Weight

280g
