Brand Name: | LNEYA |
---|---|
Application: | Jacket reactors |
MF: | 2012012 |
Other Names: | SUNDI |
CAS No.: | 1 |
Model Number: | SUNDI |
Place of Origin: | China (Mainland) |
Quick Details
Specifications
Cooling and heating temperature control system Jacket dynamic temperature control system Cooling and heating device Cooling and heating circulator Refrigeration heating circulator Refrigeration heating device Low and high temperature bath Refrigeration heating machine Refrigeration heating equipment Refrigeration heating bath Cooling and heating circulation machine Cooling and heating circulation pump Refrigeration and heating circulation pump Refrigeration and heating circulation machine Low and high temperature circulated pump
Model |
SUNDI-320 |
SUNDI-420W |
SUNDI-430W | |
Temperature range |
-30~180 |
-45~180 |
-45~180 | |
Control Mode |
Feed forward PID + Our special dynamic control calculation, PLC controller | |||
Temp. Control |
Option: process temperature control or jacket oil temperature control | |||
Temp. Difference |
Set or control the temperature difference between jacket oil and raw material process | |||
Program Editor |
20 programs, each program can edit 45 steps. | |||
Communication protocol |
MODBUS RTU Protocol, RS 485 Interface | |||
Temperature feedback |
Heat-conducting medium: PT100 Raw material process: PT100 | |||
Temp. Accuracy |
1 |
1 |
1 | |
Heating power |
2kW |
2kW |
3kW | |
Cooling capacity |
180 |
1.5kW |
1.8kW |
3kW |
50 |
1.5kW |
1.8kW |
3kW | |
0 |
1.5kW |
1.8kW |
3kW | |
-5 |
0.9kW |
1.2kW |
2kW | |
-20 |
0.6kW |
1kW |
1.5kW | |
-35 |
|
0.3kW |
0.5kW | |
Circulation pump |
Max10L/min 0.8BAR |
Max10L/min 0.8BAR |
Max20L/min 2BAR | |
Compressor |
Embraco |
Embraco |
France | |
Expansion valve |
Danfoss |
Danfoss |
Danfoss | |
KAORI | ||||
Operation Panel |
7-inch color touch screen controller, temperature curve record, data export to excel format. | |||
|
Self-diagnosis function; freezer overload protection; high pressure switch, overload relay, thermal protection device, Liquid low level protection, high temperature protection and temperature fault protection. | |||
Closed |
the whole system is full closed circulation, there is no oil mist at high temperature and no water vapor at low temperature, Pressure do not rise up when system is running. the system will supplement oil automatically at low temperature. | |||
Refrigerant |
R-404A | |||
Connection size |
DN-15 or M24*1.5 |
DN-15 or M24*1.5 |
DN-15 or M24*1.5 | |
Water-cooled type W (cooling water at 20) |
|
450L/H 1.5bar~4bar |
550L/H 1.5bar~4bar | |
Dimension |
350*550*620 |
350*550*620 |
400*600*1050 | |
Weight |
55kg |
55kg |
85kg | |
Power |
AC 220V 50HZ 2.9kW (max) |
AC 380V 50HZ 3.1kW (max) |
AC 380V 50HZ 4.5kW (max) | |
Case material |
SUS 304 |
SUS 304 |
SUS 304 | |
Optional |
Optional Ethernet interface, configure PC operating software | |||
Optional |
Optional outside touch screen display controller (separated), the communication line distance is 10 meter. | |||
Optional power |
100V 50HZ, 110V 60HZ , 230V 60HZ , 220V 60HZ three-phase, 440V~480V 60HZ three-phase |
