Product Main

Quick Details

Item Type: Light Strips
Light Source: LED
Model Number: SW-strip-5630-300LED
Brand Name: Shengwei
Place of Origin: China (Mainland)
Emitting Color: White
Certification: CCC,CE,FCC,RoHS
Lamp Body Material: Copper
Working Lifetime(Hour): 50000hours
Working Temperature(℃):
Color Temperature(CCT): 2700-12000K
CRI (Ra>): 90
Lamp Luminous Flux(lm): 95lm/w
Lamp Power: 30W
Input Voltage(V): 12V
Type: Flex LED Strips
LED Light Source: 5630

Specifications

Packaging & Delivery
Packaging Detail: smd 5630 led strip,5m/rolls
Delivery Detail: 4-6 working days
Specifications

5630 smd led,smd 5630 led,SAMSUNG smd 5630 led strip
Input:DC12V
2.power:120W/5M
3.color:white
4.CE RoHs

5630 smd led,smd 5630 led,smd 5630 led strip

SAMSUNG 5630 led strip specifications:

Light Color: White
LED Quantity : SAMSUNG 5630 smd led ,60pcs/m
Input Voltage : DC12V

Operating Current  : 10 A
Input Power : 30 W
Water Proof :IP20/IP66
Lumens :2000Lm/5 meter
Size: 5000mmX10mm
View Angle: 120°  Gross weight
Illumination range 0.5-1.5 m
Storage Temperature -40°C----+80°C
Operating emperature -25°C----+60°C

SAMSUNG 5630 led strip feature:

1.  Width: 10mm, 5m/rolll;

2.  Viewing angle : 120 degrees;

3.  Cuttable at 3 leds

4.  Color available:single color.

5.  Assembled with 300 pcs  SAMSUNG 5630 smd led / 5 meter packing

6.  Long life: 50,000 hours;

7.  Board material: FPC;`

8.  Input: DC 12V , 24watts per meter;

SAMSUNG 5630 led strip connection diagram:
