Products Features:
(1)LED Power: 2*10W.
(2)Lamp Consumption:24W.
(3)Output: 1800-2100lm.
(4)Input voltage:100-277v AC, 50-60hz
(5)Beam Angle:30°/60°
(6)CRI:> 80.
(7)Working Temperature:-40°C-45°C.
(8)Storage Temperature: -25°C-65°C.
(9)Color of housing: white, black, silver.
(10)Life span: 50,000+hrs.
(11)Certificate: CE/RoHS/SASO
(12)Warranty: 3 years.


COB Parameter(Each COB):
(1)PCB: Ceramic.
(2)Chip Brand: Epistar 10*23.
(3)Output: 1000-1200lm.
(4)Chip Qty: 160 pcs.
(5)CRI> 82.
(6)Voltage:30-36vDC
(7)Current: 320-350mA.

Driver Parameter:
(1)Brand: Lifud (LED Friend).
(2)Input:100-277v AC.
(3)Output: 27-42vDC, 350mA.
(4)Power effect: 0.9-0.98.
(5)Power Efficiency: 80%
(6)Certificate:CE/CQC/RoHS/SAA/UL/TUV

Dimmable: Triac or Dali is available.
Meanwell APC-12-350 is optional.


Product Datasheet:



Part No.	Color	CCT	Output	Size
SW-COB-2*10W-WW	warm white	2900-3200k	1800-1900lm	240x120x85mm
SW-COB-2*10W-NW	natural white	4000-4500k	1900-2100lm
SW-COB-2*10W-CW	cool white	5900-6300k	2000-2200lm
